FRONT CALIPER (MODEL K2/K3/K4)

VL1500B INTRUDER 1998 (W) USA (E03)

Front caliper (model k2/k3/k4) diagram VL1500B INTRUDER 1998 (W) USA (E03)

FRONT CALIPER (MODEL K2/K3/K4) VL1500B INTRUDER 1998 (W) USA (E03)

FRONT CALIPER (MODEL K2/K3/K4) VL1500B INTRUDER 1998 (W) USA (E03)

prices are in EUR

ref

part #

description

quantity



5910033DD0999
ref:

CALIPER ASSY,FR,R

€ 518.00



5930033DD0999
ref:

CALIPER ASSY,FR,L

€ 386.00

1

5930033831
ref: 1

PISTON SET

€ 65.50

2

5930033841
ref: 2

SEAL SET,PISTON

€ 26.50

3-1

5911533D00
ref: 3-1

SPRING,PAD,R

€ 12.00

3-2

5931533D00
ref: 3-2

SPRING,PAD,L

€ 11.50

4

5911244B00
ref: 4

BOOT,AXLE

€ 8.00

5

5914144B01
ref: 5

PIN,PAD

€ 8.00

6

5931336500
ref: 6

INSULATOR,AXLE

€ 5.50

7

6914245000
ref: 7

CLIP,PAD PIN

€ 4.50

8

5911633D00
ref: 8

GUIDE,PAD

€ 6.50

9

5912118410
ref: 9

BLEEDER

€ 8.00

10

5515666310
ref: 10

CAP,BLEEDER PLUG

€ 6.00

11-1

5910233880
ref: 11-1

PAD & SHIM SET (NAS)

€ 65.50

11-2

5930233870
ref: 11-2

PAD & SHIM SET (NAS)

€ 65.50

12

5917133D00
ref: 12

SHIM,PAD

€ 10.00

13

5917233D00
ref: 13

SHIM,PAD NO.2

€ 10.50

14

0910610038
ref: 14

BOLT(10X33)

€ 4.50

15

0925008014
ref: 15

CAP(OD:12)

€ 3.50
