HANDLE SWITCH (MODEL K4)

VL1500B INTRUDER 1998 (W) USA (E03)

Handle switch (model k4) diagram VL1500B INTRUDER 1998 (W) USA (E03)

HANDLE SWITCH (MODEL K4) VL1500B INTRUDER 1998 (W) USA (E03)

HANDLE SWITCH (MODEL K4) VL1500B INTRUDER 1998 (W) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3720048E90
ref: 1

SWITCH ASSY,HANDLE,R

€ 232.00

2

0211205167
ref: 2

SCREW

€ 2.50

3

0940714407
ref: 3

CLAMP(L:145)

€ 4.00

4

3740010F60
ref: 4

SWITCH ASSY,HANDLE,L

€ 220.00

5

0211205167
ref: 5

SCREW

€ 2.50

6

0940714407
ref: 6

CLAMP(L:145)

€ 4.00
