BATTERY

DR-Z250 2005 (K5) USA (E03) DRZ250 DR Z250

Battery diagram DR-Z250 2005 (K5) USA (E03) DRZ250 DR Z250

BATTERY DR-Z250 2005 (K5) USA (E03) DRZ250 DR Z250

BATTERY DR-Z250 2005 (K5) USA (E03) DRZ250 DR Z250

prices are in EUR

ref

part #

description

quantity

1

3361013E20
ref: 1
33610-40B20

BATTERY ASSY (FTZ5L-BS)

€ 54.50

2

3382013E00
ref: 2

WIRE,BATTERY PLUS

€ 0.00

3

3362415D00
ref: 3

CAP,BATTERY PLUS

€ 6.00

4

3386013E01
ref: 4

WIRE,BATTERY MINUS

€ 0.00

5

3365226E00
ref: 5

PROTECTOR(20X90)X1.0

€ 3.00

6

3365137000
ref: 6

PROTECTOR(170X95X3.0)

€ 5.00

6

3365137000
ref: 6

PROTECTOR(170X95X3.0)

€ 5.00

7

3365213E00
ref: 7
33652-29F00

PROTECTOR,BATTERY

€ 3.00

8

3365207D00
ref: 8

PROTECTOR(80X80X2)

€ 4.50

8

3365207D00
ref: 8

PROTECTOR(80X80X2)

€ 4.50
