STAND

GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)

Stand diagram GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)

STAND GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)
STAND GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)
STAND GR650X 1983 (D) (E01 E02 E06 E22 E24 E39)
prices are in EUR
ref
part #
description
quantity
1
4210015500
ref: 1
STAND,CENTER
4210015500
€ 72.50
2
4210015510
ref: 2
E22,E26
STAND, CENTER
4210015510
€ 86.50
3
0918010040
ref: 3
SPACER(10X16X38.8)
0918010040
€ 3.00
4
0910110018
ref: 4
BOLT
0910110018
€ 5.50
5
0832121108
ref: 5
LOCK WASHER
0832121108
€ 2.00
6
0938510001
ref: 6
CLIP
0938510001
€ 1.50
7-1
0944318010
ref: 7-1
SPRING
€ 4.00
7-2
0944318006
ref: 7-2
E22,E26
SPRING
0944318006
€ 5.50
8
0932110001
ref: 8
CUSHION
0932110001
€ 2.50
9
4231015500
ref: 9
STAND,SIDE
€ 40.50
10
0944313013
ref: 10
SPRING
0944313013
€ 8.00
11
4231015510
ref: 11
E16,E18,E22,E26
STAND, PROP
€ 28.50
12
0944317006
ref: 12
E16,E18
SPRING
0944317006
€ 4.50
13
0944311008
ref: 13
E22,E26
SPRING
0944311008
€ 5.50
14
0944319002
ref: 14
E22,E26
SPRING, OUTER
0944319002
€ 4.00
15
0911110019
ref: 15
BOLT L:30
0911110019
€ 4.50
16
0831022106
ref: 16
NUTM10X1.25X8
€ 2.00
17
0932007001
ref: 17
CUSHION
0932007001
€ 4.00
