GEAR SHIFTING

GSF400 1991 (M) (E02 E04 E16 E21 E22 E24 E25 E34 E53)

Gear shifting diagram GSF400 1991 (M) (E02 E04 E16 E21 E22 E24 E25 E34 E53)

GEAR SHIFTING GSF400 1991 (M) (E02 E04 E16 E21 E22 E24 E25 E34 E53)
GEAR SHIFTING GSF400 1991 (M) (E02 E04 E16 E21 E22 E24 E25 E34 E53)
GEAR SHIFTING GSF400 1991 (M) (E02 E04 E16 E21 E22 E24 E25 E34 E53)
prices are in EUR
ref
part #
description
quantity
1
2521130B00
ref: 1
FORK,GEAR SHIFT NO.1
2521130B00
€ 38.50
2
2522134C00
ref: 2
FORK,GEAR SHIFT NO.2
€ 84.00
3
2523130B01
ref: 3
FORK,GEAR SHIFT NO.3
2523130B01
€ 79.00
4
0918006086
ref: 4
SPACER(6X9.8X6)
0918006086
€ 2.50
5
2541130B00
ref: 5
L:144
SHAFT,GEAR SHIFT FORK
2541130B00
€ 14.00
6
2531034C01
ref: 6
CAM,GEAR SHIFT
2531034C01
€ 112.00
7
2532231301
ref: 7
GEAR,GEARSHIFT CAM DRIVE
2532231301
€ 14.50
8
2532334201
ref: 8
PAWL,GEAR SHIFT NO.1
2532334201
€ 6.00
9
2532434201
ref: 9
PAWL,GEAR SHIFT NO.2
2532434201
€ 6.00
10
0926105003
ref: 10
PIN(5X8)
0926105003
€ 1.50
11
0944004003
ref: 11
SPRING
0944004003
€ 1.50
12
2533132C00
ref: 12
LIFTER,GEAR SHIFT PAWL
€ 4.00
13
0212206128
ref: 13
SCREW
0212206128
€ 3.00
14
2534138401
ref: 14
GUIDE,GEAR SHIFT CAM
€ 8.50
15
0212206128
ref: 15
SCREW
0212206128
€ 3.00
16
0916730007
ref: 16
WASHER,LOCK
€ 2.50
17
2535038400
ref: 17
STOPPER,GEAR SHIFTING
€ 8.00
18
0944309033
ref: 18
SPRING
0944309033
€ 7.00
19
2538137400
ref: 19
PLATE,SHIFT CAM STOPPER
€ 10.50
20
0918025095
ref: 20
SPACER (25X30.1X6)
€ 0.00
21
0621104063
ref: 21
PIN 4X6
0621104063
€ 2.00
22
2551010D00
ref: 22
SHAFT,GEAR SHIFT
€ 49.00
23
0918012126
ref: 23
SPACER(12X20X13.8)
0918012126
€ 0.00
24
0821112262
ref: 24
WASHER
0821112262
€ 1.50
25
0944426015
ref: 25
SPRING
0944426015
€ 4.00
26
2567136A00
ref: 26
STOPPER,GEAR SHIFT ARM
2567136A00
€ 3.00
27
0833131126
ref: 27
CIRCLIP,12 MM
0833131126
€ 2.00
28
0928512002
ref: 28
OIL SEAL
0928512002
€ 7.00
29
0916014003
ref: 29
WASHER (14.2X22X1)
0916014003
€ 1.00
30
2552032C00
ref: 30
ARM,GEAR SHIFT LINK
2552032C00
€ 46.00
31
0110706207
ref: 31
BOLT
0110706207
€ 2.00
32
0831011067
ref: 32
NUT 6MM
€ 2.50
33
2552507A01
ref: 33
ROD,GEAR SHIFT LINK
2552507A01
€ 12.00
34
0914006011
ref: 34
NUT
0914006011
€ 1.50
35
2560010D01
ref: 35
LEVER ASSEMBLY,GEAR SHIFTING
€ 64.00
36
2565220C00
ref: 36
RUBBER,GEAR SHIFT PEDAL
2565220C00
€ 8.00
37
0916118003
ref: 37
WASHER(18.2X27X1)
€ 3.00
38
3772032C00
ref: 38
BASE ASSY,NEUTRAL SW TERMINAL
3772032C00
€ 38.50
39
0928026003
ref: 39
O-RING (D:2.4 ID:26.2)
0928026003
€ 2.50
40-1
0211275168
ref: 40-1
MODEL M
SCREW
0211275168
€ 2.50
40-2
0913805003
ref: 40-2
MODEL N/P
SCREW
€ 1.50
41
0920905011
ref: 41
PIN(5X15.5)
0920905011
€ 2.00
42
0944004010
ref: 42
SPRING
0944004010
€ 1.50
43
0940406422
ref: 43
CLAMP
€ 2.50
