FUEL COCK (MODEL T/V)

GSXR750 1997 (V) (E02 E04 E18 E22 E24 E25 E34 E39) / P37

Fuel cock (model t/v) diagram GSXR750 1997 (V) (E02 E04 E18 E22 E24 E25 E34 E39) / P37

FUEL COCK (MODEL T/V) GSXR750 1997 (V) (E02 E04 E18 E22 E24 E25 E34 E39) / P37

FUEL COCK (MODEL T/V) GSXR750 1997 (V) (E02 E04 E18 E22 E24 E25 E34 E39) / P37

prices are in EUR

ref

part #

description

quantity

1

4430033E00
ref: 1

COCK ASSEMBLY,FUEL

€ 113.00

2

4435133E00
ref: 2

O RING,JOINT

€ 5.50

3

0912806057
ref: 3

BOLT(6X20)

€ 2.00

4

0916806026
ref: 4

GASKET(6.4X11.5X0.8) (NAS)

€ 3.50

5

0935570125600
ref: 5

HOSE(7X12X600)

€ 26.00

6

0940111407
ref: 6

CLIP

€ 2.50
