2ND AIR (EXCEPT E18)

VL1500 1999 (X)

2nd air (except e18) diagram VL1500 1999 (X)

2ND AIR (EXCEPT E18) VL1500 1999 (X)

2ND AIR (EXCEPT E18) VL1500 1999 (X)

prices are in EUR

ref

part #

description

quantity

1

1861010F10
ref: 1

BRACKET,2ND AIR SPRT

€ 60.00

2

1874010F10
ref: 2

PLATE,2ND AIR HEAT GUARD

€ 30.50

3

1874510F10
ref: 3

SHEET,2ND AIR HEAT GUARD PLATE

€ 15.00

4

1878010F10
ref: 4

COVER ASSY,2ND AIR

€ 195.50

5

1878310F10
ref: 5

HOLDER,2ND AIR

€ 12.50

6

1878848E00
ref: 6

CUSHION

€ 11.50

7

0150006403
ref: 7

BOLT

€ 2.00

8

0916006140
ref: 8

WASHER

€ 2.00

9

0932010014
ref: 9

CUSHION

€ 4.00
