ELECTRICAL

ref

part #

description

quantity

1

3180021E20
ref: 1

RELAY ASSY,STARTING MOTOR

€ 69.00

1A

3186121E20
ref: 1A

COVER,RELAY ASSEMBLY

€ 10.50

1B

0948130101
ref: 1B

FUSE(30A)

€ 6.00

2

0912806013
ref: 2

SCREW(6X8)

€ 1.50

3

3381010F00
ref: 3

WIRE,STARTER MOTOR LEAD

€ 29.00

4

3186148B10
ref: 4

CAP,STARTER MOTOR LEAD

€ 4.50

5

3280033E00
ref: 5

RECTIFIER ASSEMBLY

€ 368.00

6

0214206253
ref: 6

SCREW

€ 1.50

7-1

3290010F00
ref: 7-1

IGNITOR ASSY

€ 780.50

7-2

3290010F30
ref: 7-2
E18

IGNITER ASSY

€ 896.00

8

0916006066
ref: 8

WASHER(6.5X20X1.6)

€ 2.00

9

0918006248
ref: 9

SPACER(6.1X8X9.5)

€ 2.50

10

0932009009
ref: 10

CUSHION

€ 5.00

11

0214206303
ref: 11

SCREW

€ 2.00

12

0831610063
ref: 12

NUT

€ 2.50

13

3342038B00
ref: 13

COIL ASSY,IGNITION

€ 151.00

14

0918006195
ref: 14

SPACER(6.4X10X18)

€ 3.50

15

0154705403
ref: 15

BOLT

€ 2.50

16

3342010F00
ref: 16

COIL ASSEMBLY,IGNITION,FRONT

€ 151.00

17

0918006195
ref: 17

SPACER(6.4X10X18)

€ 3.50

18

0154705403
ref: 18

BOLT

€ 2.50

19

3351038B00
ref: 19

CAP,SPARK PLUG

€ 21.50

20

3354124510
ref: 20

SEAL,SPARK PLUG CAP

€ 7.00

21

3354238B00
ref: 21

SEAL,HIGH TENSION CORD

€ 4.50

22

3874026E00
ref: 22

RELAY ASSY

€ 32.50

23

3397010F00
ref: 23

SOLENOID ASSY,DECOMP

€ 235.50

24

3397110F00
ref: 24

STOPPER,DECOMP SOLENOID

€ 6.00

25

0155008163
ref: 25

BOLT

€ 3.00

26

3365219B00
ref: 26

CUSHION,BATTERY(80X27X3)

€ 4.50

27

3397231D10
ref: 27

CUSHION,DECOMP

€ 4.50

28

5890010F00
ref: 28

CABLE ASSY,DECOMP FR

€ 20.00

29

0940725401
ref: 29

CLAMP(L:235)

€ 4.00

all assemblies
