FRONT DAMPER
VZR1800BZ BOULEVARD 2014 (L4) USA (E03)
Front damper diagram VZR1800BZ BOULEVARD 2014 (L4) USA (E03)
FRONT DAMPER VZR1800BZ BOULEVARD 2014 (L4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5110348G30
ref: 1
DAMPER ASSY,FR FORK,R
€ 1,048.50
2
5111048G30
ref: 2
TUBE,INNER,R
€ 593.50
3
5115827C00
ref: 3
WASHER
€ 4.00
4
5115348G00
ref: 4
SEAL,OIL
€ 16.50
5
5115627C00
ref: 5
RING,STOPPER
€ 3.00
6
5117342F00
ref: 6
SEAL,DUST
€ 21.00
7
5114705H00
ref: 7
BOLT
€ 4.50
8
5114841310
ref: 8
GASKET (NAS)
€ 2.50
9
5114648G20
ref: 9
CYLINDER
€ 294.00
10
5113048G30
ref: 10
TUBE,OUTER
€ 463.00
11
5117148G20
ref: 11
SPRING,FR
€ 78.50
12
5117621H00
ref: 12
SPACER,SPRING
€ 17.00
13
5135213A60
ref: 13
NUT,ROD
€ 1.50
14
5135148G30
ref: 14
CAP
€ 52.00
15
5111748G00
ref: 15
O RING
€ 2.00
16
5110448G30
ref: 16
DAMPER ASSY,FR FORK,L
€ 1,088.50
17
5112048G30
ref: 17
TUBE,INNER,L
€ 599.50
18
5115827C00
ref: 18
WASHER
€ 4.00
19
5115348G00
ref: 19
SEAL,OIL
€ 16.50
20
5115627C00
ref: 20
RING,STOPPER
€ 3.00
21
5117342F00
ref: 21
SEAL,DUST
€ 21.00
22
5114705H00
ref: 22
BOLT
€ 4.50
23
5114841310
ref: 23
GASKET (NAS)
€ 2.50
24
5114648G20
ref: 24
CYLINDER
€ 294.00
25
5113048G30
ref: 25
TUBE,OUTER
€ 463.00
26
5117148G20
ref: 26
SPRING,FR
€ 78.50
27
5117621H00
ref: 27
SPACER,SPRING
€ 17.00
28
5135213A60
ref: 28
NUT,ROD
€ 1.50
29
5135148G30
ref: 29
CAP
€ 52.00
30
5111748G00
ref: 30
O RING
€ 2.00
31
5132839G20
ref: 31
BOLT,HOLDER HANDLE UPR
€ 6.50
