FUEL TANK

GS1100S 1983 (D) USA (E03)

Fuel tank diagram GS1100S 1983 (D) USA (E03)

FUEL TANK GS1100S 1983 (D) USA (E03)

FUEL TANK GS1100S 1983 (D) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

4411049304YD8
ref: 1

TANK,FUEL(SILVER)

€ 575.50

2

681104930075G
ref: 2

TAPE SET, FUEL TANK

€ 49.00

3

681113320005F
ref: 3

EMBLEM(ORANGE)

€ 15.50

4

4420034820
ref: 4

CAP SET,FUEL TANK

€ 135.50

5

0932910007
ref: 5

CUSHION

€ 3.00

6

4454134500
ref: 6

CUSHION,FUEL TANK CTR

€ 13.00

7

0932014013
ref: 7

CUSHION

€ 3.00

8

0932010020
ref: 8

CUSHION

€ 4.00

9

0916006134
ref: 9

WASHER(6.5X24X1.6)

€ 1.50

10

0918006271
ref: 10

SPACER(6.5X9X18)

€ 2.00

11

0150006307
ref: 11

BOLT

€ 2.50
