CRANKCASE COVER
GS500F 2004 (K4) USA (E03)
Crankcase cover diagram GS500F 2004 (K4) USA (E03)
CRANKCASE COVER GS500F 2004 (K4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1134101D10
ref: 1
COVER,CLUTCH
€ 148.50
2
1148244110
ref: 2
GASKET,CLUTCH COVER (NAS)
€ 17.50
3
0421113189
ref: 3
PIN
€ 2.50
4
0910306216
ref: 4
BOLT(6X55)
€ 2.50
5
0910306214
ref: 5
BOLT(6X35)
€ 2.50
6
0910306212
ref: 6
BOLT(6X25)
€ 2.50
7
1197044110
ref: 7
GAUGE,OIL LEVEL
€ 20.50
8
0928026006
ref: 8
O RING(D:3.1,ID:26.4)
€ 3.00
9
0924714012
ref: 9
09247-14026
PLUG (14X12)
€ 3.50
10
0916814002
ref: 10
09168-14004
GASKET(13.8X18.8X4.8) (NAS)
€ 2.50
11
1138101D10
ref: 11
COVER,CONTACT BREAKER
€ 41.00
12
0910305016
ref: 12
BOLT(5X16)
€ 2.00
13
6823301D10
ref: 13
EMBLEM,CONTACT BREAKER COVER
€ 19.00
14
1135101D10
ref: 14
COVER,MAGNETO
€ 150.00
15
1148344110
ref: 15
GASKET,MAGNETO COVER (NAS)
€ 12.50
16
0421113189
ref: 16
PIN
€ 2.50
17
0910306214
ref: 17
BOLT(6X35)
€ 2.50
18
6823301D10
ref: 18
EMBLEM,CONTACT BREAKER COVER
€ 19.00
19
1136101D10
ref: 19
COVER,ENGINE SPROCKET
€ 110.00
20
0421109129
ref: 20
PIN
€ 2.00
21
0910306239
ref: 21
BOLT(6X65)
€ 3.50
22
0910306238
ref: 22
BOLT(6X50)
€ 2.50
23
0910306215
ref: 23
BOLT(6X40)
€ 2.00
24
1138701D10
ref: 24
CAP,CLUTCH RELEASE ADJUST
€ 30.50
25
0212205127
ref: 25
SCREW
€ 2.50
26
1138201D00
ref: 26
COVER,STARTER MOTOR
€ 20.50
27
0154705083
ref: 27
01547-0508B
BOLT
€ 2.50
28
3782033D10
ref: 28
SWITCH ASSY,OIL PRESSURE
€ 29.00
29
3782233D00
ref: 29
BOLT,OIL PRESSURE SWITCH
€ 3.00
