CRANKSHAFT
GS500F 2004 (K4) USA (E03)
Crankshaft diagram GS500F 2004 (K4) USA (E03)
CRANKSHAFT GS500F 2004 (K4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1216044100
ref: 1
12160-44101
ROD ASSEMBLY,CONNECTING
€ 135.50
2
0915908033
ref: 2
NUT
€ 2.50
3-1
1216401D010A0
ref: 3-1
BEARING,CRANK PIN
€ 13.50
3-2
1216401D010B0
ref: 3-2
BEARING,CRANK PIN
€ 14.50
3-3
1216401D010C0
ref: 3-3
BEARING,CRANK PIN
€ 14.50
3-4
1216401D010D0
ref: 3-4
BEARING,CRANK PIN
€ 15.00
4
1222001D02
ref: 4
CRANKSHAFT
€ 1,167.50
5
0920203016
ref: 5
PIN
€ 1.50
6-1
1222901D010A0
ref: 6-1
BEARING,CRANKSHAFT(GREEN)
€ 10.50
6-2
1222901D010B0
ref: 6-2
BEARING,CRANKSHAFT(BLACK)
€ 11.00
6-3
1222901D010C0
ref: 6-3
BEARING,CRANKSHAFT(BROWN)
€ 11.00
6-4
1222901D010D0
ref: 6-4
BEARING,CRANKSHAFT(YELLOW)
€ 11.00
7
1222844106
ref: 7
BEARING,CRANK THRUST
€ 8.50
8
0928322015
ref: 8
SEAL,OIL(22X40X8)
€ 10.50
9
1211101D010F0
ref: 9
PISTON (74.00MM)
€ 77.00
10
1214001D20
ref: 10
RING SET,PISTON
€ 57.00
11
1215145501
ref: 11
PIN,PISTON (18MM)
€ 14.00
12
0938118002
ref: 12
CIRCLIP
€ 1.50
13
1210001D00050
ref: 13
PISTON SET(OS:0.5)
€ 112.50
14
2111144100
ref: 14
GEAR,PRIMARY DRIVE NO.28
€ 57.50
15
0914024007
ref: 15
NUT
€ 4.50
16
0916425001
ref: 16
WASHER
€ 4.50
17
0834131059
ref: 17
KEY
€ 3.00
