FRONT DAMPER (NOT FOR U.S. MARKET)
GS500F 2004 (K4) USA (E03)
Front damper (not for u.s. market) diagram GS500F 2004 (K4) USA (E03)
FRONT DAMPER (NOT FOR U.S. MARKET) GS500F 2004 (K4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5110301DB0
ref: 1
DAMPER ASSY,FR FORK,R
€ 482.50
2
5110401DB0
ref: 2
DAMPER ASSY,FR FORK,L
€ 721.00
3
5113001DA0
ref: 3
TUBE,OUTER,R
€ 404.50
4
5114001DA0
ref: 4
TUBE,OUTER,L
€ 424.00
5
5116701D00
ref: 5
METAL,SLIDE
€ 10.50
6
5115849500
ref: 6
WASHER
€ 4.00
7
5115326F00
ref: 7
SEAL,OIL
€ 13.50
8
5115640301
ref: 8
RING,STOPPER
€ 4.50
9
5117326F00
ref: 9
SEAL,DUST
€ 17.50
10
5111001D60
ref: 10
TUBE,INNER
€ 372.00
11
5112101D00
ref: 11
PISTON
€ 11.50
12
5119501D00
ref: 12
PIECE,OIL LOCK
€ 16.50
13
5114601D00
ref: 13
CYLINDER
€ 102.50
14
5119613A10
ref: 14
RING,PISTON
€ 7.00
15
5117701D00
ref: 15
SPRING,REBOUND
€ 8.00
16
5114716510
ref: 16
BOLT,FORK CYLINDER(10X25)
€ 3.50
17
5114841310
ref: 17
GASKET (NAS)
€ 2.50
18
0155008407
ref: 18
BOLT
€ 3.50
19
5117101D60
ref: 19
SPRING,MAIN
€ 67.50
20
5117201D00
ref: 20
WASHER
€ 5.00
21
5117601DB0
ref: 21
SPACER
€ 10.50
22
5119201D60
ref: 22
WASHER,UPR
€ 4.50
23
5135124D00
ref: 23
BOLT,FORK
€ 49.00
24
5111738260
ref: 24
O RING
€ 2.50
25
5120101DA0
ref: 25
PROTECTOR,FR FORK
€ 19.50
