FRONT BRAKE HOSE (GSF1200SAV/SAW/SAX)
GSF1200SA 1996 (T)
Front brake hose (gsf1200sav/saw/sax) diagram GSF1200SA 1996 (T)
FRONT BRAKE HOSE (GSF1200SAV/SAW/SAX) GSF1200SA 1996 (T)
×
prices are in EUR
ref
part #
description
quantity
1
5949117E00
ref: 1
JOINT,BRAKE HOSE
€ 68.50
2
0155006163
ref: 2
BOLT
€ 2.50
3
5924027E50
ref: 3
HOSE,FR BRAKE NO.2,R
€ 75.00
4
5944027E50
ref: 4
HOSE,FR BRAKE NO.2,L
€ 63.00
5
0936010043
ref: 5
BOLT UNION
€ 6.50
6
0916110009
ref: 6
WASHER(10X15X1.5)
€ 2.00
7
0936010041
ref: 7
BOLT UNION
€ 6.50
8
0916110009
ref: 8
WASHER(10X15X1.5)
€ 2.00
9
5926027E50
ref: 9
CLAMP,FR BRAKE HOSE,R
€ 16.50
10
5926027E00
ref: 10
CLAMP,FR BRAKE HOSE,L
€ 17.50
11
5571027E50
ref: 11
SENSOR,FR WHEEL ABS
€ 182.50
12
5573227E50
ref: 12
CLAMP,ABS SENSOR FORK
€ 10.00
13
5573127E50
ref: 13
CLAMP,ABS SENSOR FR JOINT
€ 7.00
14
0940714407
ref: 14
CLAMP(L:145)
€ 4.00
15
0155008163
ref: 15
BOLT
€ 3.00
