HANDLE SWITCH

GSF1250SA BANDIT 2009 (K9) CALIFORNIA (E33)

Handle switch diagram GSF1250SA BANDIT 2009 (K9) CALIFORNIA (E33)

HANDLE SWITCH GSF1250SA BANDIT 2009 (K9) CALIFORNIA (E33)

HANDLE SWITCH GSF1250SA BANDIT 2009 (K9) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

1

3720038G30
ref: 1
37200-29G80

SWITCH ASSY,HANDLE,R

€ 158.00

2

021120530B
ref: 2

SCREW

€ 1.50

3

3740018H10
ref: 3
37400-18H12

SWITCH ASSY,HA

€ 184.00

4

021120525B
ref: 4

SCREW

€ 1.50

5

021120545B
ref: 5

SCREW

€ 4.00

6

0940714407
ref: 6

CLAMP(L:145)

€ 4.00
