SEAT

ref

part #

description

quantity

1

4510015H01EJY
ref: 1

SEAT ASSY

€ 194.50

2

4514945330
ref: 2

CUSHION,SUPPORT(50X25X32)

€ 2.00

3

0932110011
ref: 3

CUSHION

€ 3.00

4

4530015H00U6H
ref: 4

SEAT ASSY,PILL

€ 104.00

5

4514915H00
ref: 5

CUSHION

€ 4.50

6

4529015H00
ref: 6

STRIKER,SEAT LOCK

€ 31.50

7

4521342F00
ref: 7

CUSHION

€ 2.50

8

083193106A
ref: 8

NUT

€ 2.50

9

4522015H00
ref: 9

BRACKET,STRIKER SUPPORT

€ 58.50

10

015470630A
ref: 10

BOLT

€ 2.50

11

4519115H00
ref: 11

BOLT,SEAT FR

€ 4.00

12

9570014810
ref: 12

LOCK SET,SEAT

€ 75.50

13

4528911F00
ref: 13

PLATE,SEAT LOCK ASSY

€ 3.00

14

4528018G00
ref: 14

CABLE,SEAT LOC

€ 15.00

15

4528814F20
ref: 15

GUIDE,SEAT LOCK CABLE

€ 4.50

16-1

4555015H01YVB
ref: 16-1

BOX,SEAT TAIL(BLACK)

€ 148.00

16-2

4555015H01YHL
ref: 16-2

BOX,SEAT TAIL(RED)

€ 177.50

16-3

4555015H01YWW
ref: 16-3

BOX,SEAT TAIL(WHITE)

€ 194.50

17

4555315H00
ref: 17

CUSHION

€ 4.50

18

4719024F01
ref: 18

WASHER,FRAME COVER

€ 7.00

19-1

4621115H00YVB
ref: 19-1

HANDLE,PILLION RIDER

€ 233.00

19-2

4621115H00YHL
ref: 19-2

HANDLE,PILLION RIDER

€ 257.50

19-3

4621115H00YWW
ref: 19-3

HANDLE,PILLION RIDER

€ 233.00

20

0910608137
ref: 20

BOLT(8X33)

€ 5.50

21

4719024F11
ref: 21

WASHER,PILLION

€ 8.00

22

4621724F00
ref: 22

CUSHION,PILLION RIDER HANDLE

€ 3.00

23

4621224F11
ref: 23

HOOK,PILLION RIDER HANDLE

€ 18.50

24

0925005009
ref: 24

CAP(OD:10)

€ 2.50
