TAIL LAMP

GSX750F 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)

Tail lamp diagram GSX750F 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)

TAIL LAMP GSX750F 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)
TAIL LAMP GSX750F 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)
TAIL LAMP GSX750F 1999 (X) (E02 E04 E17 E18 E22 E24 E25 E34)
prices are in EUR
ref
part #
description
quantity
1
3571008F00
ref: 1
LAMP ASSY,RR COMBINATION
3571008F00
€ 185.50
2
3572008F00
ref: 2
LAMP UNIT
3572008F00
€ 102.50
3
3571808F00
ref: 3
SOCKET & CORD
3571808F00
€ 38.00
4
0947112083
ref: 4
BULB(12V21/5W)
0947112083
€ 6.00
5
0321105163
ref: 5
SCREW
0321105163
€ 1.50
6
0321104163
ref: 6
SCREW
0321104163
€ 1.50
7
0913905057
ref: 7
SCREW(5X12.8)
0913905057
€ 3.50
8
0914805038
ref: 8
NUT
0914805038
€ 2.50
9
0324115163
ref: 9
SCREW
0324115163
€ 2.00
10
0354105163
ref: 10
SCREW
0354105163
€ 1.50
11
3591008F00
ref: 11
LAMP ASSY,LICENSE PLATE
3591008F00
€ 163.00
12
3591208F00
ref: 12
LENS
3591208F00
€ 8.50
13
3591708F00
ref: 13
COVER
3591708F00
€ 56.00
14
3591508F00
ref: 14
HOUSING
€ 8.50
15
3591808F00
ref: 15
SOCKET & CORD
€ 20.00
16
3576608F00
ref: 16
SPACER
€ 5.50
16A
3576124B31
ref: 16A
CUSHION
3576124B31
€ 9.00
17
0947112081
ref: 17
BULB(12V5W)
0947112081
€ 1.50
18
0831620063
ref: 18
NUT
0831620063
€ 2.00
19
3592727E00
ref: 19
BRACKET,LICENSE PLATE
3592727E00
€ 10.00
20
0214206163
ref: 20
SCREW
0214206163
€ 2.50
21
0916006088
ref: 21
WASHER(6.5X20X1.6)
0916006088
€ 2.00
22
0831000063
ref: 22
NUT 6MM
0831000063
€ 2.00
23
0932106031
ref: 23
CUSHION
0932106031
€ 4.00
