SIGNAL GENERATOR

GSXR1000 2012 (L2) USA (E03)

Signal generator diagram GSXR1000 2012 (L2) USA (E03)

SIGNAL GENERATOR GSXR1000 2012 (L2) USA (E03)

SIGNAL GENERATOR GSXR1000 2012 (L2) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3322001H00
ref: 1

SENSOR ASSY,CAM POSITION

€ 108.00

2

3311047H00
ref: 2

STARTER,SIGNAL GENERATOR

€ 289.50

3

3311547H00
ref: 3

CLAMP,SIGNAL GENERATORERATOR

€ 4.50

4

3312047H00
ref: 4

ROTOR,SIGNAL GENERATOR

€ 82.00

5

0940406429
ref: 5

CLAMP(L:45)

€ 2.50

6

071300510A
ref: 6

BOLT

€ 1.50

7

071300510A
ref: 7

BOLT

€ 1.50

8

071300616A
ref: 8
07130-0616B

BOLT

€ 3.00
