PEDAL CRANK

ref

part #

description

quantity

1

6611122600
ref: 1

CRANK, RH

€ 19.50

2

6611222601
ref: 2

DOG, OUTER

€ 19.50

3

6611322601
ref: 3

DOG, INNER

€ 14.50

4

6611422600
ref: 4

SLEEVE, CRANK

€ 3.50

5

6611522600
ref: 5

STOPPER, DOG

€ 6.50

6

0944039001
ref: 6

SPRING

€ 2.00

7

0834131059
ref: 7

KEY

€ 3.00

8

0920504007
ref: 8

SPRING PIN

€ 1.50

9

0833131169
ref: 9

CIRCLIP,16MM

€ 2.00

10

6612046300
ref: 10

GEAR CRANK ASSY

€ 0.00

11

6612122600
ref: 11

CRANK, LH

€ 41.50

12

6612246300
ref: 12

SPROCKET

€ 0.00

13

6612322600
ref: 13

SPACER

€ 7.50

14

0831022068
ref: 14

NUT 6MM

€ 2.50

15

0832121068
ref: 15

LOCK WASHER

€ 2.50

16

0910006067
ref: 16

BOLT(6X14)

€ 2.50

17

6612722600
ref: 17

FREE WHEEL

€ 41.50

18

5246104000
ref: 18

PIN

€ 0.00

19

0915906017
ref: 19

NUT

€ 2.50

20

6613146700
ref: 20

SHAFT, CRANK

€ 0.00

21

6614046100
ref: 21

PEDAL ASSY, RH

€ 29.00

22

6615046100
ref: 22

PEDAL ASSY, LH

€ 26.50

23

6616322600
ref: 23

COLLOR, DUST SEAL CRANK

€ 2.50

24

6616122600
ref: 24

DUST SEAL, CRANK

€ 4.00

25

6616222600
ref: 25

CAP, CRANK

€ 3.50
