MAGNETO
VS1400GLP 2000 (Y)
Magneto diagram VS1400GLP 2000 (Y)
MAGNETO VS1400GLP 2000 (Y)
×
prices are in EUR
ref
part #
description
quantity
1
3210138B01
ref: 1
<-32101-38B00
STATOR ASSEMBLY
€ 1,055.00
2
3210238B10
ref: 2
ROTOR ASSY
€ 743.00
3
0910314001
ref: 3
BOLT(14X43)
€ 7.00
4
0942005007
ref: 4
KEY
€ 3.00
5
0154706303
ref: 5
BOLT,G/S SWITC
€ 3.00
6
0154705103
ref: 6
BOLT
€ 2.50
7
3237145C00
ref: 7
CLAMP,MAGNETO LEAD WIRE
€ 3.00
8
0154705103
ref: 8
BOLT
€ 2.50
9
0940408206
ref: 9
<-09404-08418
CLAMP(L:65 T:0.8)
€ 3.50
10
0940406432
ref: 10
<-09404-06429
CLAMP(L:65)
€ 2.50
