REAR COMBINATION LAMP
VS1400GLP 2000 (Y)
Rear combination lamp diagram VS1400GLP 2000 (Y)
REAR COMBINATION LAMP VS1400GLP 2000 (Y)
×
prices are in EUR
ref
part #
description
quantity
1
3571038B20
ref: 1
LAMP ASSY,RR COMBINATION
€ 234.00
2
3571238A20
ref: 2
LENS
€ 81.00
3
3571331D00
ref: 3
<-35713-38A00
GASKET (NAS)
€ 9.50
4
3572344130
ref: 4
SCREW
€ 1.50
5
3562743010
ref: 5
GASKET (NAS)
€ 2.00
6
0947112083
ref: 6
BULB(12V21/5W)
€ 6.00
7
3576538B20
ref: 7
CUSHION
€ 18.50
8
3576426470
ref: 8
CUSHION
€ 2.50
9
3576644720
ref: 9
SPACER,COMBINATION LAMP
€ 3.00
10
0150006303
ref: 10
MODEL T
BOLT
€ 2.50
10
0150006303
ref: 10
MODEL V/W/X
BOLT
€ 2.50
10A
0911606103
ref: 10A
MODEL V/W/X
BOLT(6X30)
€ 2.50
11
0916006057
ref: 11
MODEL T
WASHER
€ 2.00
11
0916006057
ref: 11
MODEL V
WASHER
€ 2.00
11
0916006109
ref: 11
MODEL W/X
WASHER(6.5X18X1.6)
€ 2.00
12
0930812009
ref: 12
GROMMET
€ 3.00
13
0940406432
ref: 13
<-09404-06429
CLAMP(L:65)
€ 2.50
14
3591038A21
ref: 14
LAMP ASSY,LICENSE
€ 240.00
15
3591738A20
ref: 15
COVER,LICENSE LAMP
€ 121.50
16
3591238A20
ref: 16
LENS
€ 13.00
17
3591338A30
ref: 17
GASKET,LICENSE LAMP (NAS)
€ 2.00
18
3576638A30
ref: 18
SPACER
€ 2.00
19
0832101043
ref: 19
WASHER,LOCK
€ 2.00
20
0831000047
ref: 20
NUT
€ 2.00
21
0947112140
ref: 21
BULB(12V5W,BF150-40160A)
€ 4.00
22
3597024D60
ref: 22
REFLECTOR ASSY,RR
€ 19.50
23
0831610053
ref: 23
NUT
€ 2.50
24
3598338B20
ref: 24
CUSHION
€ 5.50
25
3597738B20
ref: 25
SPACER,RR RR
€ 8.00
26
0351104163
ref: 26
SCREW
€ 1.50
