CAM CHAIN
GSXR1000 2014 (L4) USA (E03)
Cam chain diagram GSXR1000 2014 (L4) USA (E03)
CAM CHAIN GSXR1000 2014 (L4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1276040F01
ref: 1
CHAIN,CAMSHAFT DRIVE
€ 117.50
2
1277147H00
ref: 2
GUIDE,CAM CHAIN NO.1
€ 24.00
3
1278235F10
ref: 3
GUIDE CAM CHAIN NO,2
€ 17.00
4
1281147H00
ref: 4
TENSIONER,CAM CHAIN
€ 52.50
5
1281231G00
ref: 5
BOLT,CAM CHAIN TENSIONER
€ 4.00
6
1283047H00
ref: 6
ADJUSTER ASSY,TENSIONER
€ 193.50
7
1283702H00
ref: 7
GASKET,TENSIONER ADJUSTER (NAS)
€ 7.00
8
071300625A
ref: 8
BOLT
€ 2.50
