STARTING MOTOR
GSXR1000 2014 (L4) USA (E03)
Starting motor diagram GSXR1000 2014 (L4) USA (E03)
STARTING MOTOR GSXR1000 2014 (L4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
3110047H00
ref: 1
MOTOR ASSY,STARTING
€ 938.50
2
3115040F01
ref: 2
HOUSING ASSY
€ 80.50
3
3115349210
ref: 3
SEAL,OIL
€ 15.00
4
3117540F01
ref: 4
FRAME ASSY
€ 97.00
5
3126432C10
ref: 5
O RING
€ 9.00
6
3128140F00
ref: 6
BOLT
€ 7.00
7
3136132C10
ref: 7
PLATE,LOCK
€ 2.50
8
3136110200
ref: 8
RING,SNAP
€ 2.50
9
3115640F01
ref: 9
O RING(COLLAR:BROWN)
€ 8.00
10
3136138300
ref: 10
SHIM
€ 1.50
11
0910306223
ref: 11
BOLT(6X20)
€ 2.50
12
0913705004
ref: 12
SCREW(5X8)
€ 2.00
