FRONT DAMPER
RMX450Z 2011 (L1) USA (E03)
Front damper diagram RMX450Z 2011 (L1) USA (E03)
FRONT DAMPER RMX450Z 2011 (L1) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5110302J00
ref: 1
DAMPER ASSY,FR FORK,R
€ 1,181.00
2
5111028H10
ref: 2
TUBE,INNER,R
€ 327.50
3
5112128H10
ref: 3
BUSH
€ 11.50
4
5116728H10
ref: 4
BUSH,GUIDE
€ 18.50
5
5115836F00
ref: 5
SPACER,SEAL
€ 5.00
6
5115337F80
ref: 6
SEAL,OIL
€ 13.50
7
5115627C40
ref: 7
RING,OIL SEAL STOPPER
€ 3.50
8
5117337F80
ref: 8
SEAL,DUST
€ 16.50
9
5113028H01
ref: 9
TUBE,OUTER
€ 727.50
10-1
5117128H00
ref: 10-1
SPRING,FR(K=0.47)
€ 112.00
10-2
5117128H10
ref: 10-2
SPRING,FR(K=0.45)
€ 112.00
10-2
5117128H10
ref: 10-2
SPRING,FR(K=0.45)
€ 112.00
10-3
5117128H20
ref: 10-3
SPRING,FR(K=0.49)
€ 112.00
10-3
5117128H20
ref: 10-3
SPRING,FR(K=0.49)
€ 112.00
11
5117037FC0
ref: 11
BOLT,CTR
€ 139.50
12
5117736E20
ref: 12
O RING
€ 2.50
13
5135102J00
ref: 13
BOLT,FORK
€ 206.50
14
5111737F80
ref: 14
O RING
€ 3.50
15
5112328H10
ref: 15
BUSH
€ 18.00
16
5117436E40
ref: 16
O RING
€ 2.50
17
5117537F80
ref: 17
O RING
€ 3.50
18
5135736F20
ref: 18
BOLT,PLUG
€ 8.00
19
5135828E30
ref: 19
O RING,PLUG
€ 2.50
20
5111837F80
ref: 20
O RING
€ 4.00
21
5119002J00
ref: 21
ROD,DAMPER
€ 596.50
22
5119110H10
ref: 22
ROD,PUSH
€ 13.50
23
5132837F80
ref: 23
BOLT
€ 5.00
24
5121137FC0
ref: 24
STOPPER,RING
€ 5.00
25
5110402J00
ref: 25
DAMPER ASSY,FR FORK,L
€ 1,181.00
26
5112028H10
ref: 26
TUBE,INNER,L
€ 327.50
27
5112128H10
ref: 27
BUSH
€ 11.50
28
5116728H10
ref: 28
BUSH,GUIDE
€ 18.50
29
5115836F00
ref: 29
SPACER,SEAL
€ 5.00
30
5115337F80
ref: 30
SEAL,OIL
€ 13.50
31
5115627C40
ref: 31
RING,OIL SEAL STOPPER
€ 3.50
32
5117337F80
ref: 32
SEAL,DUST
€ 16.50
33
5113028H01
ref: 33
TUBE,OUTER
€ 727.50
34-1
5117128H00
ref: 34-1
SPRING,FR(K=0.47)
€ 112.00
34-2
5117128H10
ref: 34-2
SPRING,FR(K=0.45)
€ 112.00
34-2
5117128H10
ref: 34-2
SPRING,FR(K=0.45)
€ 112.00
34-3
5117128H20
ref: 34-3
SPRING,FR(K=0.49)
€ 112.00
34-3
5117128H20
ref: 34-3
SPRING,FR(K=0.49)
€ 112.00
35
5117037FC0
ref: 35
BOLT,CTR
€ 139.50
36
5117736E20
ref: 36
O RING
€ 2.50
37
5135102J00
ref: 37
BOLT,FORK
€ 206.50
38
5111737F80
ref: 38
O RING
€ 3.50
39
5112328H10
ref: 39
BUSH
€ 18.00
40
5117436E40
ref: 40
O RING
€ 2.50
41
5117537F80
ref: 41
O RING
€ 3.50
42
5135736F20
ref: 42
BOLT,PLUG
€ 8.00
43
5135828E30
ref: 43
O RING,PLUG
€ 2.50
44
5111837F80
ref: 44
O RING
€ 4.00
45
5119002J00
ref: 45
ROD,DAMPER
€ 596.50
46
5119110H10
ref: 46
ROD,PUSH
€ 13.50
47
5132837F80
ref: 47
BOLT
€ 5.00
48
5121137FC0
ref: 48
STOPPER,RING
€ 5.00
49
5150128H10
ref: 49
PROTECTOR,FR FORK,R
€ 74.00
50
5151128H00
ref: 50
PROTECTOR,FR FORK,L
€ 83.50
51
0911106098
ref: 51
BOLT(6X10)
€ 2.00
52
6866129F00DPZ
ref: 52
EMBLEM,SUZUKI
€ 25.00
