WATER PUMP
RMX450Z 2011 (L1) USA (E03)
Water pump diagram RMX450Z 2011 (L1) USA (E03)
WATER PUMP RMX450Z 2011 (L1) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1741028H00
ref: 1
CASE,WATER PUMP
€ 64.00
2
1743128H00
ref: 2
O RING,WATER PUMP CASE
€ 8.50
3
015470630A
ref: 3
BOLT
€ 2.50
4
015470660A
ref: 4
BOLT
€ 2.50
5
015470670A
ref: 5
BOLT
€ 2.50
6
0916806023
ref: 6
GASKET(5.8X13X1.2) (NAS)
€ 2.00
7
0920608001
ref: 7
PIN(6.2X8X11)
€ 2.00
8
1746137F00
ref: 8
SEAL,WATER PUMP OIL
€ 5.00
9
1749135G00
ref: 9
IMPELLER,WATER PUMP
€ 13.00
10
1751028H01
ref: 10
SHAFT,WATER PUMP
€ 53.00
11
0918106003
ref: 11
SHIM(6X14X1)
€ 2.00
12
0918108186
ref: 12
SHIM(8X18X0.5)
€ 1.50
