FRONT FORK
RV50 1983 (D) (E01)
Front fork diagram RV50 1983 (D) (E01)
FRONT FORK RV50 1983 (D) (E01)
×
prices are in EUR
ref
part #
description
quantity
1
5110627790
ref: 1
FORK ASSY, FRONT
€ 0.00
2
5113127790
ref: 2
OUTER TUBE
€ 91.00
3
5111027790
ref: 3
INNER TUBE
€ 112.50
4
5114731030
ref: 4
BOLT
€ 3.50
5
5114831030
ref: 5
GASKET (NAS)
€ 4.00
6
5115313200
ref: 6
SEAL,OIL
€ 14.50
7
5115648130
ref: 7
RING,OIL SEAL STOPPER
€ 3.50
8
5157127410
ref: 8
BOOT
€ 15.00
9
5117227790
ref: 9
SEAT, SPRING
€ 4.00
10
5117327430
ref: 10
GUIDE, SPRING
€ 3.00
11
5117127410
ref: 11
SPRING
€ 22.50
12
5157527410
ref: 12
COVER,STEERING STEM
€ 12.50
13-1
5141027431
ref: 13-1
STEERING STEM
€ 164.00
13-2
5141027740
ref: 13-2
E22
STEERING STEM
€ 164.00
14
5162133001
ref: 14
RACE,STEERING OUTER LWR
€ 10.00
15
5155327410
ref: 15
CUSHION
€ 7.00
16
5118122011
ref: 16
O RING
€ 3.00
17
5131127790291
ref: 17
HEAD, STEERING STEM
€ 79.00
18
5135622012
ref: 18
WASHER,STEM HEAD(10.5X30X3.2)
€ 4.00
19
5135120010
ref: 19
BOLT,FORK INNER TUBE
€ 25.00
20
5135607030
ref: 20
WASHER
€ 5.00
21
5145127431
ref: 21
BOLT
€ 4.50
22
0832121108
ref: 22
LOCK WASHER
€ 2.00
23
5621127200291
ref: 23
HOLDER,HANDLE UPR
€ 13.50
24
0852121088
ref: 24
LOCK WASHER
€ 0.00
25
0120408357
ref: 25
BOLT
€ 3.50
26-1
515302778004Y
ref: 26-1
MODEL X
COVER, UPPER RH
€ 33.50
26-2
515302778010G
ref: 26-2
MODEL X
COVER, UPPER RH
€ 33.50
26-3
5153027780163
ref: 26-3
MODEL X
COVER, UPPER RH
€ 0.00
26-4
515302778005H
ref: 26-4
MODEL D
COVER, UPPER RH
€ 33.50
26-5
515302778014C
ref: 26-5
MODEL D
COVER, UPPER RH
€ 33.50
27-1
515402778004Y
ref: 27-1
MODEL X
COVER, UPPER LH
€ 97.50
27-2
515402778010G
ref: 27-2
MODEL X
COVER, UPPER LH
€ 97.50
27-3
5154027780163
ref: 27-3
MODEL X
COVER, UPPER LH
€ 0.00
27-4
515402778005H
ref: 27-4
MODEL D
COVER, UPPER LH
€ 97.50
27-5
515402778014C
ref: 27-5
MODEL D
COVER, UPPER LH
€ 97.50
28-1
515302774200N
ref: 28-1
MODEL X E22
COVER, UPPER RH
€ 33.50
28-2
515302774204Y
ref: 28-2
MODEL X E22
COVER, UPPER RH
€ 33.50
28-3
515302774205E
ref: 28-3
MODEL X E22
COVER, UPPER RH
€ 33.50
28-4
515302774205H
ref: 28-4
MODEL D E22
COVER, UPPER RH
€ 33.50
28-5
515302774214C
ref: 28-5
MODEL D E22
COVER, UPPER RH
€ 33.50
29-1
515402774200N
ref: 29-1
MODEL X E22
COVER, UPPER LH
€ 0.00
29-2
515402774204Y
ref: 29-2
MODEL X E22
COVER, UPPER LH
€ 0.00
29-3
515402774205E
ref: 29-3
MODEL X E22
COVER, UPPER LH
€ 0.00
29-4
515402774205H
ref: 29-4
MODEL D E22
COVER, UPPER LH
€ 0.00
29-5
515402774214C
ref: 29-5
MODEL D E22
COVER, UPPER LH
€ 0.00
30
5191025311
ref: 30
LOCK ASSY,STEERING
€ 22.50
31
0211205128
ref: 31
SCREW
€ 2.50
32
0832121058
ref: 32
LOCK WASHER
€ 2.00
33
5190022662
ref: 33
E22
LOCK ASSEMBLY,STEERING (NEI
€ 168.50
