TURN SIGNAL LAMP (E22)

RV50 1983 (D) (E01)

Turn signal lamp (e22) diagram RV50 1983 (D) (E01)

TURN SIGNAL LAMP (E22) RV50 1983 (D) (E01)
TURN SIGNAL LAMP (E22) RV50 1983 (D) (E01)
TURN SIGNAL LAMP (E22) RV50 1983 (D) (E01)
prices are in EUR
ref
part #
description
quantity
1
3560346191999
ref: 1
LAMP, FRONT TURN SIGNAL
€ 51.50
2
3560327640999
ref: 2
LAMP, REAR TURN SIGNAL
€ 79.50
3
3561228620
ref: 3
LENS
3561228620
€ 10.50
4
3561328620
ref: 4
GASKET (NAS)
3561328620
€ 7.00
5
0211204258
ref: 5
SCREW 4X25
0211204258
€ 2.00
6
3562743010
ref: 6
GASKET (NAS)
3562743010
€ 2.00
7
0947106033
ref: 7
EXECUTED LOCALLY
BULB (6V,21W)
€ 0.00
8
0832221108
ref: 8
WASHER
0832221108
€ 2.50
9-1
3861027590
ref: 9-1
MODEL X
RELAY, TURN SIGNAL
€ 0.00
9-2
3861027591
ref: 9-2
MODEL D
RELAY, TURN SIGNAL
€ 0.00
