HEADLAMP (E22)

GS450E 1980 (T) (E01 E02 E04 E17 E18 E21 E22 E24 E25 E34 E39)

Headlamp (e22) diagram GS450E 1980 (T) (E01 E02 E04 E17 E18 E21 E22 E24 E25 E34 E39)

HEADLAMP (E22) GS450E 1980 (T) (E01 E02 E04 E17 E18 E21 E22 E24 E25 E34 E39)

HEADLAMP (E22) GS450E 1980 (T) (E01 E02 E04 E17 E18 E21 E22 E24 E25 E34 E39)

prices are in EUR

ref

part #

description

quantity

1

3510011330999
ref: 1

HEADLAMP ASSY

€ 0.00

2

3511144610
ref: 2

RIM,HEADLAMP

€ 41.00

3

3512733630
ref: 3

RETAINER,HEADLAMP

€ 16.00

4

3512111320
ref: 4

UNIT

€ 52.50

5

3513634670
ref: 5

SETTER,BULB

€ 4.00

6

3513629610
ref: 6

SCREW

€ 3.00

7

0832121058
ref: 7

LOCK WASHER

€ 2.00

8

3517233630
ref: 8

SPRING

€ 4.00

9

3515133630
ref: 9

SCREW,HEADLAMP ADJUST

€ 2.00

10

3515433630
ref: 10

SPRING

€ 2.50

11

3515215611
ref: 11

NUT

€ 3.50

12

3611830500
ref: 12

SOCKET

€ 10.00

13

0947112048
ref: 13
PHILIPS NO. 12620

BULB(12V45/40W)

€ 7.50

14

0947112063
ref: 14
PHILIPS NO. 12929

BULB(12V4W)

€ 6.00

15

0912505022
ref: 15

SCREW

€ 3.50

16

0916205003
ref: 16

WASHER,LOCK

€ 2.00

17

0916906021
ref: 17

WASHER

€ 2.50

18

5181144000291
ref: 18

HOUSING,HEADLAMP(BLACK)

€ 63.00

19

0120408257
ref: 19

BOLT

€ 2.00

20

0832211088
ref: 20

WASHER

€ 2.00

21

0832121088
ref: 21

LOCK WASHER

€ 2.00

22

0918008030
ref: 22

SPACER (8.8X12X7)

€ 3.50

23

0932912002
ref: 23

CUSHION

€ 3.00

24

5186045000
ref: 24

PLATE,HEADLAMP HOUSING

€ 2.00
