STAND

GSXR750 1985 (F) (E01 2 4 6 15 16 17 18 21 22 24 25 34 39 53)

Stand diagram GSXR750 1985 (F) (E01 2 4 6 15 16 17 18 21 22 24 25 34 39 53)

STAND GSXR750 1985 (F) (E01 2 4 6 15 16 17 18 21 22 24 25 34 39 53)
STAND GSXR750 1985 (F) (E01 2 4 6 15 16 17 18 21 22 24 25 34 39 53)
STAND GSXR750 1985 (F) (E01 2 4 6 15 16 17 18 21 22 24 25 34 39 53)
prices are in EUR
ref
part #
description
quantity
1
4231027A0113L
ref: 1
STAND,SIDE
4231027A0113L
€ 59.50
2
0944314040
ref: 2
SPRING
0944314040
€ 4.00
3-1
4231027A1113L
ref: 3-1
MODEL F/G E15,E16,E1
STAND, PROP (SILVER)
€ 0.00
3-2
4231027B1013L
ref: 3-2
MODEL H E2,E15,E16,E
STAND,PROP (SILVER)
€ 0.00
4-1
0944317018
ref: 4-1
MODEL F E15,E16,E18
SPRING
0944317018
€ 5.50
4-2
0944318016
ref: 4-2
MODEL G E2,E15,E16,E
SPRING
0944318016
€ 21.00
5-1
4231027A2113L
ref: 5-1
MODEL F/G E22
STAND, PROP (SILVER)
€ 0.00
5-2
4231027B2013L
ref: 5-2
MODEL H E22
STAND,PROP (SILVER)
€ 0.00
6
0944314030
ref: 6
E22
SPRING
0944314030
€ 6.00
7
0944322003
ref: 7
E22
SPRING
0944322003
€ 7.00
8
0911110036
ref: 8
BOLT(10X38)
0911110036
€ 5.50
9
0831022107
ref: 9
NUT
0831022107
€ 2.50
10-1
4233027A0113L
ref: 10-1
BRACKET,SIDE STAND
€ 40.50
10-2
4233027A1113L
ref: 10-2
MODEL F/G E15,E16,E1
BRACKET, PROP STAND (SILVER)
€ 29.50
10-3
4233027B10
ref: 10-3
MODEL H E2,E15,E16,E
BRACKET,PROP STAND
€ 28.50
11
0711008358
ref: 11
BOLT, FRONT RH
€ 4.50
12
4157504A00
ref: 12
CAP,ENGINE MOUNTING
4157504A00
€ 2.00
13
0916408015
ref: 13
WASHER
0916408015
€ 3.00
14
0831616088
ref: 14
NUT
0831616088
€ 2.50
15
4311027A01
ref: 15
PEDAL,BRAKE
4311027A01
€ 129.00
16
4315104701
ref: 16
RUBBER,BRAKE PEDAL
4315104701
€ 6.00
17
4312027A00
ref: 17
ARM COMP,BRAKE ROD
4312027A00
€ 28.50
18
0944314044
ref: 18
SPRING
0944314044
€ 4.00
19
4321204A00
ref: 19
WASHER,BRAKE PEDAL
4321204A00
€ 2.00
20-1
0154706208
ref: 20-1
MODEL F/G
BOLT (6X20)
0154706208
€ 2.50
20-2
0910306119
ref: 20-2
MODEL H
BOLT
€ 2.50
21
0920006037
ref: 21
PIN
0920006037
€ 5.00
22
0832221067
ref: 22
WASHER
0832221067
€ 2.00
23
0411120158
ref: 23
PIN
0411120158
€ 1.50
24
4210027A00
ref: 24
OPT
STAND,CENTER
€ 0.00
25
5721149510
ref: 25
OPT
GRIP,L
5721149510
€ 26.50
