FRAME COVER (MODEL D:E2, E4, E18, E21, E25, E39)

DR250S 1983 (D)

Frame cover (model d:e2, e4, e18, e21, e25, e39) diagram DR250S 1983 (D)

FRAME COVER (MODEL D:E2, E4, E18, E21, E25, E39) DR250S 1983 (D)
FRAME COVER (MODEL D:E2, E4, E18, E21, E25, E39) DR250S 1983 (D)
FRAME COVER (MODEL D:E2, E4, E18, E21, E25, E39) DR250S 1983 (D)
prices are in EUR
ref
part #
description
quantity
1
4711138211019
ref: 1
TO 47111-38212-019
COVER, FRAME RH (BLACK)
€ 67.00
2
681303822089A
ref: 2
TAPE SET, FRAME COVER RH
€ 0.00
3
681313823089R
ref: 3
EMBLEM, LH
€ 5.50
4
471113821105K
ref: 4
TO 47111-38212-05K
COVER, FRAME RH (BLUE)
€ 67.00
5
681303822089D
ref: 5
TAPE SET, FRAME COVER RH
€ 0.00
6
681313823089R
ref: 6
EMBLEM, LH
€ 5.50
7
471113821107P
ref: 7
TO 47111-38212-07P
COVER,FRAME,RIGHT
€ 67.00
8
681303822089B
ref: 8
TAPE SET, FRAME COVER RH
€ 10.00
9
681313823089R
ref: 9
EMBLEM, LH
€ 5.50
10
471113821110V
ref: 10
TO 47111-38212-10V
COVER, FRAME RH (WHITE)
€ 67.00
11
681303822076U
ref: 11
TAPE,FRAME COVER,RIGHT
€ 0.00
12
681313823073F
ref: 12
EMBLEM
€ 4.50
13
4711138211163
ref: 13
TO 47111-38212-163
COVER, FRAME RH (YELLOW)
€ 67.00
14
681303822074H
ref: 14
TAPE SET, FRAME COVER RH
€ 0.00
15
681313823073F
ref: 15
EMBLEM
€ 4.50
16
4721138221019
ref: 16
COVER, FRAME LH (BLACK)
€ 57.50
17
681403822089A
ref: 17
TAPE SET, FRAME COVER LH
€ 0.00
18
681313823089R
ref: 18
EMBLEM, LH
€ 5.50
19
472113822105K
ref: 19
COVER, FRAME LH (BLUE)
€ 57.50
20
681403822089D
ref: 20
TAPE SET, FRAME COVER LH
€ 0.00
21
681313823089R
ref: 21
EMBLEM, LH
€ 5.50
22
472113822107P
ref: 22
COVER, FRAME LH (RED)
€ 57.50
23
681403822089B
ref: 23
TAPE SET, FRAME COVER LH
€ 10.50
24
681313823089R
ref: 24
EMBLEM, LH
€ 5.50
25
472113822110V
ref: 25
COVER, FRAME, LH
€ 57.50
26
681403822076U
ref: 26
TAPE,FRAME COVER,LEFT
€ 0.00
27
681313823073F
ref: 27
EMBLEM
€ 4.50
28
4721138221163
ref: 28
COVER, FRAME LH (YELLOW)
€ 57.50
29
681403822074H
ref: 29
TAPE SET, FRAME COVER LH
€ 0.00
30
681313823073F
ref: 30
EMBLEM
€ 4.50
31
0932003005
ref: 31
CUSHION
0932003005
€ 2.00
32
0932008018
ref: 32
CUSHION
0932008018
€ 4.00
33
4712238201
ref: 33
HEAT SHIELD,FRAME COVER
€ 34.00
