TURN SIGNAL LAMP (MODEL K/M/R E2)

GS125E 1982 (Z) SWEDEN (E17)

Turn signal lamp (model k/m/r e2) diagram GS125E 1982 (Z) SWEDEN (E17)

TURN SIGNAL LAMP (MODEL K/M/R E2) GS125E 1982 (Z) SWEDEN (E17)

TURN SIGNAL LAMP (MODEL K/M/R E2) GS125E 1982 (Z) SWEDEN (E17)

prices are in EUR

ref

part #

description

quantity

1

3560139370
ref: 1

LAMP ASSY, FRONT TURN SIGNAL

€ 78.50

2

3561202460
ref: 2

LENS

€ 9.00

3

3561328620
ref: 3

GASKET (NAS)

€ 7.00

4

0321104207
ref: 4

SCREW

€ 1.50

5

3562743010
ref: 5

GASKET (NAS)

€ 2.00

6

0947112045
ref: 6

BULB(12V21W)

€ 5.00

7

3569536590
ref: 7

SPACER

€ 6.00

8

3569032200
ref: 8

CUSHION

€ 38.50

9

0916010006
ref: 9

WASHER (10.5X30X2.3)

€ 2.50

10

0832121106
ref: 10

LOCK WASHER

€ 3.00

11-1

0831012106
ref: 11-1
MODEL K/M

NUT

€ 2.00

11-2

0831000107
ref: 11-2
MODEL R

NUT

€ 2.50

12

3666033000
ref: 12

LEAD WIRE,EARTH

€ 5.00

13-1

3560339370
ref: 13-1
MODEL K/M

LAMP ASSY, REAR TURN SIGNAL

€ 78.50

13-2

3560326420999
ref: 13-2
MODEL R

LAMP ASSY,RR TURNSIGNAL

€ 78.50

14

3565202470
ref: 14

LENS

€ 7.00

15

3561328620
ref: 15

GASKET (NAS)

€ 7.00

16

0321104207
ref: 16

SCREW

€ 1.50

17

3562743010
ref: 17

GASKET (NAS)

€ 2.00

18

0947112045
ref: 18

BULB(12V21W)

€ 5.00

19

3569536590
ref: 19

SPACER

€ 6.00

20

0932015004
ref: 20

CUSHION

€ 5.00

21

0916010006
ref: 21

WASHER (10.5X30X2.3)

€ 2.50

22

0832121106
ref: 22

LOCK WASHER

€ 3.00

23-1

0831012106
ref: 23-1
MODEL K/M

NUT

€ 2.00

23-2

0831000107
ref: 23-2
MODEL R

NUT

€ 2.50

24

3686244000
ref: 24

LEAD WIRE,EARTH

€ 4.00

25

3562005310
ref: 25

BRACKET,RR TURNSIGNAL LAMP

€ 5.50

26

3666033000
ref: 26

LEAD WIRE,EARTH

€ 5.00

27

3861031310
ref: 27

RELAY ASSEMBLY,TURN SIGNAL

€ 54.50
