FRONT WHEEL (MODEL X)
GS550L 1982 (Z) USA (E03)
Front wheel (model x) diagram GS550L 1982 (Z) USA (E03)
FRONT WHEEL (MODEL X) GS550L 1982 (Z) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5411149300291
ref: 1
54111-49301-291
WHEEL (1.9X1.85)
€ 0.00
2
0812363027
ref: 2
BEARING
€ 19.00
3
5473018400
ref: 3
SPACER,FR HUB BEARING
€ 13.00
4
5471149000
ref: 4
AXLE,FR
€ 79.50
5
0831431128
ref: 5
08314-3112A
NUT 12MM
€ 2.00
6
0411130308
ref: 6
04111-3030A
COTTER PIN
€ 1.50
7
5474018402
ref: 7
SPACER,FR AXLE,R
€ 18.50
8
5474149101
ref: 8
SPACER
€ 14.00
9
0832221128
ref: 9
08322-01127
WASHER
€ 2.00
10
0916015002
ref: 10
WASHER(15.5X26X2.3)
€ 2.00
11
5487145000
ref: 11
COVER,FR HUB,R
€ 6.00
12
5460045200
ref: 12
54600-49100
BOX ASSEMBLY,SPEEDOMETER GEAR
€ 90.00
13
5921134500
ref: 13
DISC,BRAKE
€ 128.00
14
0910008140
ref: 14
BOLT(8X25)
€ 2.00
15
0916908016
ref: 15
WASHER
€ 3.50
16-1
5510047510
ref: 16-1
TIRE,FRONT
€ 94.50
16-2
5510047550
ref: 16-2
TIRE,FRONT
€ 79.50
17
5520029010
ref: 17
TUBE 2.75-19 070-483MM
€ 0.00
18-1
5541147001
ref: 18-1
BALANCER,WHEEL
€ 4.00
18-2
5541247001
ref: 18-2
BALANCER,WHEEL
€ 3.50
