AIR CLEANER (MODEL Z)
GSX1100EX 1983 (D) (E02)
Air cleaner (model z) diagram GSX1100EX 1983 (D) (E02)
AIR CLEANER (MODEL Z) GSX1100EX 1983 (D) (E02)
×
prices are in EUR
ref
part #
description
quantity
1
1371049500
ref: 1
CASE COMP,AIR CLEANER
€ 0.00
2
1388149020
ref: 2
TUBE,AIR CLEANER OUTLET
€ 16.00
3
1388547030
ref: 3
RING,CARBURETOR AIR INLET HOSE
€ 8.00
4
0940264306
ref: 4
CLAMP
€ 6.00
5
1387000010
ref: 5
DRAIN TUBE
€ 13.50
6
0940114301
ref: 6
CLIP
€ 2.00
7
1385100220
ref: 7
TUBE,BREATHER
€ 13.50
8
0940114301
ref: 8
CLIP
€ 2.00
9
1370049840
ref: 9
CASE SET, REAR
€ 181.50
10
1378049310
ref: 10
FILTER ASSY
€ 29.50
11
1379549000
ref: 11
HOSE,AIR CLEANER
€ 34.50
12
1379649000
ref: 12
BAND
€ 6.00
13
0211205128
ref: 13
SCREW
€ 2.50
14
0832121058
ref: 14
LOCK WASHER
€ 2.00
15
0110706208
ref: 15
BOLT
€ 2.00
16
0832121068
ref: 16
LOCK WASHER
€ 2.50
17
0832221068
ref: 17
WASHER
€ 2.00
up
