REAR CALIPERS

GSX1100EX 1983 (D) (E02)

Rear calipers diagram GSX1100EX 1983 (D) (E02)

REAR CALIPERS GSX1100EX 1983 (D) (E02)
REAR CALIPERS GSX1100EX 1983 (D) (E02)
REAR CALIPERS GSX1100EX 1983 (D) (E02)
prices are in EUR
ref
part #
description
quantity
0
6910045020
ref: 0
MODEL Z
CALIPER ASSEMBLY,REAR
€ 843.50
0
6910045021
ref: 0
MODEL D
CALIPER ASSEMBLY,REAR
€ 843.50
1-1
6910045850
ref: 1-1
MODEL Z
PISTON SET
€ 241.00
1-2
6910045860
ref: 1-2
MODEL D
PISTON SET
€ 241.00
2-1
6913045020
ref: 2-1
MODEL Z
PAD,BRAKE
€ 66.50
2-2
6913045021
ref: 2-2
MODEL D
PAD,BRAKE (MCA)
6913045021
€ 66.50
3
5910718410
ref: 3
SEAL,PISTON
5910718410
€ 17.00
4
6910845000
ref: 4
BOOT,PISTON
6910845000
€ 10.00
5
6910745000
ref: 5
SEAL,PISTON
6910745000
€ 15.50
6
6914545000
ref: 6
BOLT,HOUSING
6914545000
€ 7.00
7
6914145000
ref: 7
PIN,PAD
6914145000
€ 6.50
8
6914245000
ref: 8
CLIP,PAD PIN
6914245000
€ 4.50
9
6914345001
ref: 9
SPRING
6914345001
€ 8.00
10
6915145000
ref: 10
COVER,DUST
6915145000
€ 26.50
11
5912118410
ref: 11
BLEEDER
5912118410
€ 8.00
12
5912218410
ref: 12
CAP,BREATHER
5912218410
€ 6.00
13
6915245001
ref: 13
SHIM,RR CALIPER
6915245001
€ 9.50
14
0152710308
ref: 14
BOLT
€ 3.50
