STEERING STEM

SFV650A GLADIUS 2014 (L4) USA (E03)

Steering stem diagram SFV650A GLADIUS 2014 (L4) USA (E03)

prices are in EUR

ref

part #

description

quantity

5131144H00
ref: 1

HEAD,STEERING STEM

€ 205.50

5132844H00
ref: 2

BOLT

€ 4.00

5132844H00
ref: 3

BOLT

€ 4.00

5135338A01
ref: 4
51353-24B00

NUT,CAP

€ 21.50

5135449G00
ref: 5

WASHER

€ 9.00

5141044H00
ref: 6

STEM,STEERING

€ 561.50

5164412C00
ref: 7

SEAL,STEERING LWR

€ 5.50

0926530020
ref: 8

BEARING(30X55X17)

€ 45.50

5148244H00
ref: 9

CAP

€ 11.00

5621144H00
ref: 10

HOLDER,HANDLE

€ 21.00

6828147HA0
ref: 11

EMBLEM,"S"

€ 7.00

0916408015
ref: 12

WASHER

€ 3.00

0713008257
ref: 13

BOLT

€ 3.50

0925006011
ref: 14

CAP(OD:11)

€ 2.50

5163131F00
ref: 15

NUT,STEERING STEM

€ 8.00

5164340502
ref: 16

DUST SEAL,STEERING UPR

€ 8.00

0926525038
ref: 17

BEARING(25X47X15)

€ 49.00
