Buy Suzuki GS Parts Online


CRANKSHAFT BALANCER

GS450L 1980 (T) (E02 E21 E22 E24 E25)

Crankshaft balancer diagram GS450L 1980 (T) (E02 E21 E22 E24 E25)

CRANKSHAFT BALANCER GS450L 1980 (T) (E02 E21 E22 E24 E25)
CRANKSHAFT BALANCER GS450L 1980 (T) (E02 E21 E22 E24 E25)
CRANKSHAFT BALANCER GS450L 1980 (T) (E02 E21 E22 E24 E25)
prices are in EUR
ref
part #
description
quantity
1
1265044100
ref: 1
BALANCER,CRANKSHAFT
€ 223.00
2
1266644000
ref: 2
GEAR,CRANK BALANCER DRIVE
1266644000
€ 128.00
3
0916024017
ref: 3
WASHER
€ 12.00
4
0944015007
ref: 4
SPRING
0944015007
€ 23.50
5
0920108001
ref: 5
PIN
0920108001
€ 3.50
6
0918024004
ref: 6
SPACER
€ 7.00
7
0916012039
ref: 7
WASHER(12X50X3)
0916012039
€ 8.00
8
0110712208
ref: 8
BOLT
€ 3.00
9-1
1222944100010
ref: 9-1
METAL CRANKSHAFT
1222944100010
€ 10.50
9-2
1222944100020
ref: 9-2
METAL CRANKSHAFT
1222944100020
€ 11.00
9-3
1222944100030
ref: 9-3
METAL CRANKSHAFT
1222944100030
€ 11.00
9-4
1222944100040
ref: 9-4
METAL CRANKSHAFT
1222944100040
€ 11.00
