HANDLE BAR (GSX750ESE/EFE)

GSX750ES 1983 (D) 1 2 4 6 15 16 17 18 21 22 24 25 26 27 30 34 39

Handle bar (gsx750ese/efe) diagram GSX750ES 1983 (D) 1 2 4 6 15 16 17 18 21 22 24 25 26 27 30 34 39

HANDLE BAR (GSX750ESE/EFE) GSX750ES 1983 (D) 1 2 4 6 15 16 17 18 21 22 24 25 26 27 30 34 39

HANDLE BAR (GSX750ESE/EFE) GSX750ES 1983 (D) 1 2 4 6 15 16 17 18 21 22 24 25 26 27 30 34 39

prices are in EUR

ref

part #

description

quantity

1

5611131330
ref: 1

HANDLEBAR

€ 20.00

2

5621131301
ref: 2
FLAT TYPE

HOLDER,HANDLEBAR,RIGHT

€ 163.50

3

5622131301
ref: 3
FLAT TYPE

HOLDER,HANDLEBAR,LEFT

€ 163.50

4

0910610024
ref: 4

BOLT 10X50

€ 3.00

5

0916410005
ref: 5

WASHER

€ 6.50

6

0938510005
ref: 6

CLIP

€ 1.50

7

0925006004
ref: 7

CAP(OD:14.5)

€ 1.50

8

0711008355
ref: 8

BOLT 8X35

€ 4.00

9

0916408015
ref: 9

WASHER

€ 3.00

10

5721543401
ref: 10

CAP,GRIP END

€ 4.00

11

5617031310
ref: 11

PAD,HANDLE

€ 27.50

12

0211206168
ref: 12

SCREW

€ 2.50

13

5617400A00
ref: 13

CAP,HANDLE PAD

€ 8.00

14

5650031301
ref: 14

MIRROR ASSEMBLY,RIGHT

€ 48.50

15

5660031301
ref: 15

MIRROR ASSEMBLY,REAR VIEW

€ 47.00

16

5650031311
ref: 16
E22,E25

MIRROR, REAR VIEW RH

€ 48.50

17

5660031311
ref: 17
E22,E25

MIRROR, REAR VIEW LH

€ 47.00

18

5650031321
ref: 18
E16,E18,E24

MIRROR, REAR VIEW RH

€ 43.50

19

5660031321
ref: 19
E16,E18,E24

MIRROR, REAR VIEW LH

€ 43.50

20

5650008030
ref: 20
E2,E4,E21

MIRROR, REAR VIEW

€ 119.50

21

5650010020
ref: 21
E2

MIRROR ASSEMBLY,REAR VIEW

€ 90.00

22

5660010020
ref: 22
E2

MIRROR ASSEMBLY,REAR VIEW

€ 92.00

23

0213206655
ref: 23

SCREW 6X65

€ 2.50

24

5627431300
ref: 24

CAP,BALANCER

€ 223.50

25

5627149400
ref: 25

BALANCER,HANDLE

€ 19.50

26

5627534400
ref: 26

SPACER,BALANCER

€ 2.50

27

5627204700
ref: 27

EXPANDER,BALANCER

€ 5.00

28

0915906024
ref: 28

NUT

€ 2.00

29

5820031300
ref: 29
FLAT TYPE

CABLE ASSY,CLUTCH

€ 22.50

30

5830031301
ref: 30
FLAT TYPE

CABLE ASSY,THROTTLE

€ 26.50

31

5841031300
ref: 31
FLAT TYPE

CABLE COMP,STARTER

€ 14.00

32

0940718301
ref: 32

CLAMP

€ 6.00

33

5862131310
ref: 33

GUIDE,CABLE/HARNESS

€ 0.00
