STAND - FOOTREST

TS125ER 1982 (Z) (1 2 6 E08 E09 E15 E17 E18 E21 E24 E30 E31 E95)

Stand - footrest diagram TS125ER 1982 (Z) (1 2 6 E08 E09 E15 E17 E18 E21 E24 E30 E31 E95)

prices are in EUR

ref

part #

description

quantity

4231005200
ref: 1

STAND,SIDE

€ 94.50

0944317007
ref: 2

SPRING

€ 4.50

0910010067
ref: 3

BOLT(10X30)

€ 3.50

0831022108
ref: 4

NUT

€ 2.50

4351048701
ref: 5

HOLDER,FR FOOTREST,R

€ 18.50

0151710258
ref: 6

BOLT

€ 3.00

4355041102
ref: 7

FOOTREST,FRONT

€ 30.50

4356048500
ref: 8

FOOTREST,FRONT,LEFT

€ 31.50

0920010008
ref: 9

PIN

€ 3.00

0411120208
ref: 10

PIN 20X20

€ 1.50

0944815004
ref: 11

SPRING

€ 2.50

4361044000
ref: 12

BAR,PILLION FOOTREST

€ 14.50

4361203001
ref: 13

RUBBER,PILLION FOOTREST

€ 3.50

0916019006
ref: 14

WASHER (19.5X32X2)

€ 2.00

0920006010
ref: 15

PIN

€ 2.50

0411120208
ref: 16

PIN 20X20

€ 1.50
