REAR BRAKE

GS1100GK 1982 (Z) GENERAL EXPORT (E01)

Rear brake diagram GS1100GK 1982 (Z) GENERAL EXPORT (E01)

REAR BRAKE GS1100GK 1982 (Z) GENERAL EXPORT (E01)

REAR BRAKE GS1100GK 1982 (Z) GENERAL EXPORT (E01)

prices are in EUR

ref

part #

description

quantity

1

4311049450
ref: 1

PEDAL,BRAKE

€ 76.50

2

4312045350
ref: 2

ARM,BRAKE PEDAL ROD

€ 30.50

3

0110708358
ref: 3

BOLT

€ 3.50

4

0832121088
ref: 4

LOCK WASHER

€ 2.00

5

0944837017
ref: 5

SPRING

€ 4.00

6

0920006029
ref: 6

PIN

€ 1.50

7

0411120158
ref: 7

PIN

€ 1.50

8

0832201067
ref: 8

WASHER

€ 2.00

9

0150006207
ref: 9

BOLT

€ 2.00

10

0831000067
ref: 10

NUT

€ 2.50
