CRANKCASE

ref

part #

description

quantity

1

1130048864
ref: 1

CRANKCASE ASSY

€ 2,303.00

2

1131933E50
ref: 2

PIN,CRANKCASE

€ 4.00

3

0910310408
ref: 3

BOLT(10X100)

€ 7.00

4

0910310406
ref: 4

BOLT(10X115)

€ 11.00

5

015470645A
ref: 5

BOLT

€ 2.50

6

015470670A
ref: 6

BOLT

€ 2.50

7

071300850A
ref: 7

BOLT

€ 3.50

8

071300865A
ref: 8

BOLT

€ 3.00

9

071300885A
ref: 9

BOLT

€ 3.00

10

0916806023
ref: 10

GASKET(5.8X13X1.2) (NAS)

€ 2.00

11

0916808016
ref: 11

GASKET(8.2X14X1) (NAS)

€ 1.00

12

0916810031
ref: 12

GASKET(10.2X20X2).3 (NAS)

€ 2.00

13-1

1222848G000A0
ref: 13-1

WASHER,CRANK THRUST

€ 8.50

13-1

1222848G000A0
ref: 13-1

WASHER,CRANK THRUST

€ 8.50

13-2

1222848G000B0
ref: 13-2

WASHER,CRANK THRUST

€ 8.50

13-3

1222848G000C0
ref: 13-3

WASHER,CRANK THRUST

€ 8.50

13-4

1222848G000D0
ref: 13-4

WASHER,CRANK THRUST

€ 8.50

13-5

1222848G000E0
ref: 13-5

WASHER,CRANK THRUST

€ 8.50

13-6

1222848G000F0
ref: 13-6

WASHER,CRANK THRUST

€ 8.50

14

0928008012
ref: 14

O RING(D:1.9,ID:7.8)

€ 4.00

15

0928012009
ref: 15

O RING(D:1.9,ID:12.6)

€ 2.50

16

0928004004
ref: 16

O RING(D:1.2,ID:4)

€ 2.00

17

0949380005
ref: 17

JET(8)

€ 12.00

18

0949380005
ref: 18

JET(8)

€ 12.00

19

1139048G00
ref: 19

JET,PISTON COOLING

€ 42.50

20

0910606075
ref: 20

BOLT(6X12)

€ 2.50

21

0928005007
ref: 21

O RING(D:1.2,ID:4.7)

€ 2.00

22

1152148G00
ref: 22

PLATE,OIL SEPARATOR

€ 11.00

23

015470612A
ref: 23

BOLT

€ 2.00

24

1197148G01
ref: 24

GAUGE,OIL LEVEL

€ 8.50

25

0928017003
ref: 25

O RING(D:3.1,ID:16.8)

€ 2.00

26

0916816002
ref: 26

GASKET(16X22X2) (NAS)

€ 2.00

27

0924816012
ref: 27

PLUG,16X8

€ 4.50

28

0916814002
ref: 28
09168-14004

GASKET(13.8X18.8X4.8) (NAS)

€ 2.50

29

0924814012
ref: 29

PLUG,14X12

€ 5.00

30

0916812002
ref: 30

GASKET(12.1X16.2X3.7) (NAS)

€ 2.00

31

0924712006
ref: 31

PLUG(12X10)

€ 2.50

32

0916806023
ref: 32

GASKET(5.8X13X1.2) (NAS)

€ 2.00

33

015470612A
ref: 33

BOLT

€ 2.00

34

1161148G00
ref: 34

SPACER,ENG MTG

€ 12.50

35

1165210G00
ref: 35

BUSH,ENGINE MOUNTING

€ 24.00

36

1165210G30
ref: 36

BUSH,ENGINE MOUNTING

€ 20.00

37

0910310041A05
ref: 37

BOLT(10X215)

€ 9.00

38

0910310118
ref: 38

BOLT(10X195)

€ 7.00

39

083193110A
ref: 39

NUT

€ 3.00

40

3782033D10
ref: 40

SWITCH ASSY,OIL PRESSURE

€ 29.00

41

3782233D00
ref: 41

BOLT,OIL PRESSURE SWITCH

€ 3.00

42

1133048G00
ref: 42

COVER,BREATHER

€ 80.00

43

015470630A
ref: 43

BOLT

€ 2.50

44

1137148G00
ref: 44

COVER,GEAR SHIFT

€ 60.50

45

1148548G00
ref: 45

GASKET,GEAR SHIFT COVER(NA) (NAS)

€ 4.00

46

015470645A
ref: 46

BOLT

€ 2.50

47

0421109149
ref: 47

PIN

€ 2.00
