FUEL TANK
GS550D 1980 (T) (E02 E15 E22 E24 E25)
Fuel tank diagram GS550D 1980 (T) (E02 E15 E22 E24 E25)
FUEL TANK GS550D 1980 (T) (E02 E15 E22 E24 E25)
×
prices are in EUR
ref
part #
description
quantity
1
4410047070019
ref: 1
TANK, FUEL
€ 681.50
2
681104707071V
ref: 2
TAPE SET
€ 78.50
3
4427637001
ref: 3
CUSHION,FUEL TANK FR COVER
€ 4.00
4
441004707005K
ref: 4
TANK, FUEL
€ 681.50
5
681104707071V
ref: 5
TAPE SET
€ 78.50
6
4427637001
ref: 6
CUSHION,FUEL TANK FR COVER
€ 4.00
7
441004707000J
ref: 7
TANK, FUEL
€ 681.50
8
681104707071W
ref: 8
TAPE SET
€ 0.00
9
4427637001
ref: 9
CUSHION,FUEL TANK FR COVER
€ 4.00
10
NOTUSED
ref: 10
NO PRODUCT DESCRIPTION AVAILABLE
€ 0.00
11
NOTUSED
ref: 11
NO PRODUCT DESCRIPTION AVAILABLE
€ 0.00
12
NOTUSED
ref: 12
NO PRODUCT DESCRIPTION AVAILABLE
€ 0.00
13
6811145010
ref: 13
EMBLEM,FUEL TANK
€ 26.00
14
NOTUSED
ref: 14
NO PRODUCT DESCRIPTION AVAILABLE
€ 0.00
15
0213203065
ref: 15
SCREW 3X6
€ 2.00
16
4420023810
ref: 16
CAP ASSY,FUEL TANK FILLER
€ 60.50
17
8541370000
ref: 17
GASKET (NAS)
€ 4.50
18
4428037010
ref: 18
LOCK,FUEL TANK FR COVER
€ 36.50
19
4427047001
ref: 19
COVER,FUEL TANK,FRONT
€ 25.00
20
0110405108
ref: 20
BOLT
€ 1.50
21
0832121058
ref: 21
LOCK WASHER
€ 2.00
22
0832221058
ref: 22
WASHER
€ 2.50
23
4429037001
ref: 23
HOLDER,FUEL TANK FRONT COVER
€ 11.50
24
0110405108
ref: 24
BOLT
€ 1.50
25
0832121058
ref: 25
LOCK WASHER
€ 2.00
26
0832221058
ref: 26
WASHER
€ 2.50
27
0944617001
ref: 27
SPRING
€ 8.00
28
0211205088
ref: 28
SCREW
€ 2.00
29
0832121058
ref: 29
LOCK WASHER
€ 2.00
30
0932910007
ref: 30
CUSHION
€ 3.00
31
4454147000
ref: 31
CUSHION
€ 8.50
32
0932012013
ref: 32
CUSHION
€ 3.00
33
0932012017
ref: 33
CUSHION
€ 2.50
34
0916008002
ref: 34
WASHER (8.5X29X1.6)
€ 2.00
35
0918008067
ref: 35
SPACER(8.5X12X19)
€ 2.50
36
0110708308
ref: 36
BOLT (8X30)
€ 2.50
