FUEL TANK (MODEL Z)

GS650G 1982 (Z) (E01 E02 E04 E06 E16 E18 E21 E22 E24 E39)

Fuel tank (model z) diagram GS650G 1982 (Z) (E01 E02 E04 E06 E16 E18 E21 E22 E24 E39)

prices are in EUR

ref

part #

description

quantity

441003431013L
ref: 1

TANK ASSEMBLY,FUEL

€ 400.50

681113430005F
ref: 2

EMBLEM

€ 18.00

441003431011W
ref: 3

TANK ASSEMBLY,FUEL

€ 0.00

6811134300064
ref: 4

EMBLEM

€ 15.00

4420034301KEY
ref: 5

CAP SET,FUEL TANK

€ 135.50

0932910007
ref: 6

CUSHION

€ 3.00

4454134500
ref: 7

CUSHION,FUEL TANK CTR

€ 13.00

0932014013
ref: 8

CUSHION

€ 3.00

0932010020
ref: 9

CUSHION

€ 4.00

0916006004
ref: 10

WASHER (6.5X24X1.6)

€ 1.50

0918006072
ref: 11

SPACER

€ 2.00

0110706308
ref: 12

BOLT

€ 2.50
