OIL PUMP - OIL FILTER - GSX400F 1982 (Z) 01 02 04 06 15 16 17 18 21 22 24 25 26 34 39 48

ref

part #

description

quantity

1

1151133202
ref: 1

PAN, OIL

€ 249.00

2

1148933202
ref: 2
~E.NO.120761

GASKET

€ 22.00

3

1148933203
ref: 3
E.NO.120762~

GASKET,OIL PAN (MCA)

€ 22.00

4

0151706308
ref: 4

BOLT

€ 2.00

5

0924714001
ref: 5

PLUG

€ 5.00

6

0916814004
ref: 6

GASKET(14X19.2X2) (NAS)

€ 2.50

7

1650045810
ref: 7

ENGINE OIL FILTER SET

€ 11.50

8

1651845000
ref: 8

O RING,OIL FILTER CHAMBER CAP

€ 7.50

9

0944032004
ref: 9

SPRING

€ 13.50

10

1651234200
ref: 10

CAP,OIL FILTER

€ 47.00

11

0142106208
ref: 11

STUD 6X20

€ 2.50

12

0831311068
ref: 12

NUT

€ 2.00

13

0832221068
ref: 13

WASHER

€ 2.00

14

1640049210
ref: 14
~E.NO.112259

PUMP ASSEMBLY,OIL

€ 155.00

15

1640049220
ref: 15
E.NO.112260~

PUMP ASSY,ENGINE OIL

€ 155.00

16

1649149200
ref: 16

O-RING,OIL PUMP

€ 12.50

17

0211206258
ref: 17
~E.NO.112259

SCREW

€ 2.00

18

0910306045
ref: 18
E.NO.112260~

BOLT(6X32)

€ 3.00

19

1633145000
ref: 19

GEAR,ENG OIL PUMP DRIVEN

€ 135.50

20

0822110185
ref: 20

SHIM

€ 2.00

21

0926104009
ref: 21

PIN(4X15.8)

€ 1.50

22

0833131109
ref: 22

CIRCLIP

€ 2.00

23

1652034200
ref: 23

STRAINER,ENGINE OIL

€ 9.00

24

0211206128
ref: 24

SCREW 6X12

€ 2.00

25

1644044100
ref: 25
~E.NO.120761

REGULATOR ASSEMBLY,ENGINE

€ 37.00

26

1644044101
ref: 26
E.NO.120762~

REGULATOR, ENGINE OIL

€ 37.00

27

0821214181
ref: 27
~E.NO.120761

WASHER

€ 2.00

28

1644933200
ref: 28
E.NO.120762~

GUIDE, REGULATOR

€ 8.00

OIL PUMP - OIL FILTER

all assemblies
