TURN SIGNAL LAMP (E2, E4, E1?, E34)

GSX400F 1982 (Z) 01 02 04 06 15 16 17 18 21 22 24 25 26 34 39 48

Turn signal lamp (e2, e4, e1?, e34) diagram GSX400F 1982 (Z) 01 02 04 06 15 16 17 18 21 22 24 25 26 34 39 48

TURN SIGNAL LAMP (E2, E4, E1?, E34) GSX400F 1982 (Z) 01 02 04 06 15 16 17 18 21 22 24 25 26 34 39 48
TURN SIGNAL LAMP (E2, E4, E1?, E34) GSX400F 1982 (Z) 01 02 04 06 15 16 17 18 21 22 24 25 26 34 39 48
TURN SIGNAL LAMP (E2, E4, E1?, E34) GSX400F 1982 (Z) 01 02 04 06 15 16 17 18 21 22 24 25 26 34 39 48
prices are in EUR
ref
part #
description
quantity
1-1
3560144122999
ref: 1-1
MODEL X
LAMP ASSEMBLY,FRONT TURN SIGNAL
€ 102.00
1-2
3560145521
ref: 1-2
MODEL Z
LAMP ASSY,FR T
3560145521
€ 70.00
2
3561149230
ref: 2
RIM
3561149230
€ 11.00
3
3561249231
ref: 3
LENS
3561249231
€ 13.00
4
3561349230
ref: 4
GASKET (NAS)
3561349230
€ 5.00
5
0321104208
ref: 5
SCREW
0321104208
€ 1.50
6
3562743010
ref: 6
GASKET (NAS)
3562743010
€ 2.00
7
0947112045
ref: 7
EXECUTED LOCALLY
BULB(12V21W)
0947112045
€ 5.00
8
0932015002
ref: 8
CUSHION
0932015002
€ 4.50
9
0916010006
ref: 9
WASHER (10.5X30X2.3)
0916010006
€ 2.50
10
0832121108
ref: 10
LOCK WASHER
0832121108
€ 2.00
11
0831012108
ref: 11
NUT
0831012108
€ 2.50
12
3666033000
ref: 12
MODEL X
LEAD WIRE,EARTH
3666033000
€ 5.00
13-1
3560344172
ref: 13-1
MODEL X
LAMP, REAR TURN SIGNAL
€ 82.00
13-2
3560345521
ref: 13-2
MODEL Z
LAMP, REAR TURN SIGNAL
3560345521
€ 83.50
14
3561149230
ref: 14
RIM
3561149230
€ 11.00
13
3565244182
ref: 13
LENS
3565244182
€ 13.00
16
3561349230
ref: 16
GASKET (NAS)
3561349230
€ 5.00
17
0947112045
ref: 17
EXECUTED LOCALLY
BULB(12V21W)
0947112045
€ 5.00
18
0321104208
ref: 18
SCREW
0321104208
€ 1.50
19
3562743010
ref: 19
GASKET (NAS)
3562743010
€ 2.00
20-1
0932015002
ref: 20-1
MODEL X
CUSHION
0932015002
€ 4.50
20-2
0932015004
ref: 20-2
MODEL Z
CUSHION
0932015004
€ 5.00
21
0916010006
ref: 21
WASHER (10.5X30X2.3)
0916010006
€ 2.50
22
0832121108
ref: 22
LOCK WASHER
0832121108
€ 2.00
23
0831012108
ref: 23
NUT
0831012108
€ 2.50
24
3666033000
ref: 24
MODEL X
LEAD WIRE,EARTH
3666033000
€ 5.00
25-1
3562033200
ref: 25-1
MODEL X F.NO.~105261
BRACKET,REAR TURN SIGNAL
3562033200
€ 8.50
25-2
3562033210
ref: 25-2
MODEL X F.NO.105262~
BRACKET, REAR RH
€ 8.50
25-3
3562033211
ref: 25-3
MODEL Z
BRACKET,REAR TURN SIGNAL
3562033211
€ 8.50
26-1
3564033200
ref: 26-1
MODEL X F.NO.~105261
BRACKET,REAR TURN SIGNAL
€ 8.00
26-2
3564033210
ref: 26-2
MODEL X F.NO.105262~
BRACKET, REAR LH
€ 8.50
26-3
3564033211
ref: 26-3
MODEL Z
BRACKET,REAR TURN SIGNAL
3564033211
€ 8.50
27
3861045031
ref: 27
RELAY,TURN SIGNAL
3861045031
€ 54.50
