HANDLEBAR

GSX750S KATANA 1982 (Z) 1 2 4 6 15 16 17 18 21 22 24 25 26 30 39

Handlebar diagram GSX750S KATANA 1982 (Z) 1 2 4 6 15 16 17 18 21 22 24 25 26 30 39

HANDLEBAR GSX750S KATANA 1982 (Z) 1 2 4 6 15 16 17 18 21 22 24 25 26 30 39
HANDLEBAR GSX750S KATANA 1982 (Z) 1 2 4 6 15 16 17 18 21 22 24 25 26 30 39
HANDLEBAR GSX750S KATANA 1982 (Z) 1 2 4 6 15 16 17 18 21 22 24 25 26 30 39
prices are in EUR
ref
part #
description
quantity
1
5611149310
ref: 1
HANDLEBAR,R
5611149310
€ 138.00
2
5615149310
ref: 2
HANDLEBAR,L
5615149310
€ 131.00
3
5611349301
ref: 3
BALANCER,HANDLEBAR
5611349301
€ 26.00
4
0213206505
ref: 4
SCREW
0213206505
€ 3.00
5
5621149300
ref: 5
HOLDER,HANDLEBAR
5621149300
€ 26.00
6
0910606005
ref: 6
BOLT
€ 3.00
7
5650049300A
ref: 7
MIRROR ASSEMBLY,REAR VIEW
€ 233.50
8
5660049300A
ref: 8
MIRROR ASSEMBLY,REAR VIEW
€ 265.00
9
5650045640
ref: 9
E2
MIRROR ASSY,RH
5650045640
€ 119.50
10
5650028601
ref: 10
E4
MIRROR ASSY,RH
€ 70.00
11
5670031001
ref: 11
E2,E4
CUSHION,REAR VIEW MIRROR
5670031001
€ 18.00
12
0831022108
ref: 12
E2,E4
NUT
0831022108
€ 2.50
13
5650049310
ref: 13
E22,E25
MIRROR, REAR VIEW RH
€ 233.50
14
5660049310
ref: 14
E22,E25
MIRROR ASSY,LH
5660049310
€ 265.00
15
5650049320
ref: 15
E16,E18,E24,E26
MIRROR, REAR VIEW RH
€ 233.50
16
5660049320
ref: 16
E16,E18,E24,E26
MIRROR, REAR VIEW LH
5660049320
€ 265.00
17
5820045500
ref: 17
CABLE ASSY,CLUTCH
5820045500
€ 35.50
18
0920006011
ref: 18
PIN(L:15)
0920006011
€ 2.50
19
0411120158
ref: 19
PIN
0411120158
€ 1.50
20
5862645101
ref: 20
GUIDE,CLUTCH CABLE
5862645101
€ 4.50
21
5830045500
ref: 21
CABLE ASSEMBLY,THROTTLE
5830045500
€ 31.00
22
0940406413
ref: 22
CLAMP
0940406413
€ 2.50
23
5841049300
ref: 23
CABLE,CLUTCH
5841049300
€ 32.50
24
9620041330
ref: 24
GAUGE ASSY,AIR PRESSURE
9620041330
€ 77.50
