FRAME

SFV650 GLADIUS 2009 (K9) USA (E03)

Frame diagram SFV650 GLADIUS 2009 (K9) USA (E03)

FRAME SFV650 GLADIUS 2009 (K9) USA (E03)

FRAME SFV650 GLADIUS 2009 (K9) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

4110044H00YLF
ref: 1-1

FRAME(GRAY)

€ 1,000.00

1-2

4110044H00YUR
ref: 1-2

FRAME(GOLD)

€ 1,992.00

1-3

4110044H00YSF
ref: 1-3

FRAME(BLUE)

€ 975.00

2

4194202F00
ref: 2

SPACER,ENG HEAD MTG RR,L

€ 17.00
