CLUTCH

ref

part #

description

quantity

1

2120011000
ref: 1
N.T=59

CLUTCH HOUSING ASS'Y

€ 0.00

2

2141111000
ref: 2

CLUTCH SLEEVE HUB

€ 0.00

3

2144111000
ref: 3

CLUTCH CORK PLATE

€ 15.50

4

2145111000
ref: 4

CLUTCH STEEL PLATE

€ 0.00

5

2146011000
ref: 5

CLUTCH OUTER PLATE

€ 0.00

6

2146611000
ref: 6

C;UTCH PRESSURE PLATE

€ 0.00

7

2312111000
ref: 7
T20-17016

CLUTCH PUSH PIECE

€ 0.00

8

2316111010
ref: 8

CLUTCH PUSH PIECE

€ 42.50

9

2326011001
ref: 9

CLUTCH RELEASE ARM

€ 0.00

10

2326511000
ref: 10

CLUTCH RELEASE LEVER

€ 24.00

11

0913406003
ref: 11
O.D=6SCREW L=20 (0.79)

CLUTCH RELEASE ADJUSTING SCREW

€ 1.50

12

0914020002
ref: 12

NUT (20MM)

€ 3.50

13

0916720002
ref: 13
O.D=34 (1.34) T=0.8 (0.03)

CLUTCH SLEEVE HUB WASHER

€ 3.00

14

0918020007
ref: 14
O.D=25 (0.95) I.D=20 (0.79) W=34 (1.34)

CLUTCH HOUSING SPACER

€ 0.00

15

0926325002
ref: 15
O.D=29 (1.14) I.D=25 (0.95) W=33.8 (1.33)

PRIMARY DRIVEN GEAR BEARING 25X29X33.8

€ 8.00

16

0928210001
ref: 16
O.D=17 (0.67) I.D=9.4 (0.37) W=5 (0.2)

SEAL,OIL(10X17X5)

€ 4.00

16

2326911010
ref: 16
T20-12694
O.D=14 (0.55) I.D=10 (0.39) W=3 (0.12)

CLUTCH RELEASE ARM SHAFT OIL SEAL

€ 2.50

17

0930410003
ref: 17
O.D=14 (0.55) I.D=10 (0.39) W=10 (0.39)

BUSHING

€ 10.50

18

0938308001
ref: 18

E-RING

€ 1.50

19

0944020001
ref: 19
O.D=20.3 (0.80) I.D=15.7 (0.62) L=47.5 (1.87)

CLUTCH SPRING

€ 6.00

20

0944814001
ref: 20

CLUTCH RELEASE ARM RETURN SPRING

€ 0.00

21

0211105201
ref: 21

CROSS HEAD SCREW

€ 3.00

22

0821120383
ref: 22
O.D=38 (1.50) I.D=20(0.79) T=2.0 (0.08)

CLUTCH HOUSING THRUST WASHER

€ 6.50

23

0831131061
ref: 23

HEXAGON NUT

€ 1.50

24

0832121051
ref: 24

LOCK WASHER

€ 2.00

25

0832311201
ref: 25

LOCK WASHER

€ 1.00
