KICK STARTER

ref

part #

description

quantity

1

2621111000
ref: 1

KICK STARTER SHAFT

€ 34.50

2

2622111000
ref: 2

GUIDE,KICK SHAFT SPRING

€ 6.00

3

2622511000
ref: 3

KCIK STARTER SHAFT BUFFER

€ 0.00

4

2623108000
ref: 4

STARTER,KICK

€ 13.50

5

2623211000
ref: 5

STOPPER,KICK STARTER

€ 12.50

6

2624011000
ref: 6
N.T=39

KICK STARTER PINION

€ 25.50

7

2630011000
ref: 7

KICK STARTER LEVER ASS'Y

€ 60.50

8

2635201000
ref: 8

RUBBER,KICK STARTER PEDAL

€ 3.50

9

0913510002
ref: 9
O.D=10 (0.39) L=37.5 (1.48)

BOLT(10X37.5)

€ 5.50

10

0913906002
ref: 10

SCREW(6X19)

€ 2.50

11

0916013002
ref: 11
O.D=31.5 (1.24) I.D=13 (0.51) T=1.5 (0.06)

WASHER(13X31.5X1.5)

€ 3.00

12

0916016002
ref: 12
O.D=33 (1.30) I.D=16 (0.63) T=1.6 (0.06)

WASHER

€ 1.50

13

0916016003
ref: 13
O.D=30.5 (1.12) I.D=16 (0.63) T=1.0 (0.04)

WASHER(16X30X1)

€ 2.50

14

0916616001
ref: 14
O.D=38 (1.50) I.D=16 (0.63) T=1.2 (0.05)

WASHER

€ 1.50

15

0918016003
ref: 15
O.D=19.1 (0.75) I.D=16.7 (0.66) W=52 (2.05)

KICK STARTER SHAFT RETURN SPRING GUIDE SPACER

€ 0.00

16

0920205003
ref: 16
O.D=5 (0.20) L=10.5 (0.41)

PIN

€ 1.00

17

0925104001
ref: 17

GREASE NIPPLE CAP

€ 3.00

18

0928516001
ref: 18
O.D=30 (1.18) I.D=16 (0.63) W=8 (0.31)

OIL SEAL

€ 6.50

19

0930016002
ref: 19
O.D=22 (0.87) I.D=16 (0.63) W=17.5 (0.69)

BUSHING

€ 4.00

20

0938416001
ref: 20

SPRING,RETAINER

€ 1.50

21

0944004002
ref: 21

SPRING

€ 1.50

22

0944837001
ref: 22

SPRING

€ 16.50

23

0212106161
ref: 23

CROSS HEAD SCREW

€ 2.00

24

0422104060
ref: 24

DOWEL PIN

€ 2.00

25

0832121101
ref: 25

LOCK WASHER

€ 2.00

26

0835111000
ref: 26

GREASE NIPPLE

€ 32.00
