FRONT FORK

ref

part #

description

quantity

1

5110011601019
ref: 1

FRONT FORK ASS'Y

€ 0.00

1

5110011601078
ref: 1

FRONT FORK ASS'Y

€ 0.00

1

5110011601079
ref: 1

FRONT FORK ASS'Y

€ 0.00

2

5111011010
ref: 2

TUBE,FORK,INNER

€ 52.50

3

5113011010019
ref: 3

FRONT RIGHT OUTER TUBE

€ 0.00

3

5113011010078
ref: 3

FRONT RIGHT OUTER TUBE

€ 0.00

3

5113011010079
ref: 3

FRONT RIGHT OUTER TUBE

€ 0.00

4

5114011010019
ref: 4

FRONT LEFT OUTER TUBE

€ 95.00

4

5114011010078
ref: 4

FRONT LEFT OUTER TUBE

€ 95.00

4

5114011010079
ref: 4

FRONT LEFT OUTER TUBE

€ 95.00

5

5115111010
ref: 5
CHROME-PLATED

FORK OUTER TUBE NUT

€ 41.50

6

5115211010
ref: 6

BUSHING,GUIDE

€ 59.00

7

5115311010
ref: 7
O.D=46 (1.81) I.D=34 (1.34) W=10 (0.39)

OIL SEAL,FRONT FORK

€ 10.50

8

5115411010
ref: 8
O.D=45.3 (1.78) I.D=39.3 (1.55) T=3.0 (0.12)

O-RING,FORK OIL SEAL L

€ 4.50

9

5115811010
ref: 9
O.D=48 (1.89) I.D=35 (1.38) T=1.6 (0.06)

WASHER

€ 3.00

10

5117111600
ref: 10
O.D=48 (1.89) I.D=39 (1.54) L=178.5 (7.03) CHROME PLATED

SPRING,FRONT FORK

€ 17.00

11

5117211010
ref: 11

GUIDE,SPRING

€ 6.00

12

5117311010
ref: 12

DUST SEAL,FRONT FORK

€ 13.00

13

5118111010
ref: 13
O.D=13.6 (0.54) I.D=8.8 (0.35) T=2.4 (0.09)

FORK FITTING BOLT "O" RING

€ 2.00

14

5118203620
ref: 14

FORK DRAIN PLUG

€ 3.50

15

5118303010
ref: 15
O.D=7.3 (0.29) I.D=4.2 (0.17) T=1.5 (0.06)

GASKET,DRAIN,PLUG (NAS)

€ 3.00

16

5131111010
ref: 16

STEERING STEM HEAD

€ 0.00

17

5135111010
ref: 17
CHROME PLATED

FORK FITTING BOLT

€ 5.50

18

5135411010
ref: 18
O.D=30 (1.18) I.D=14 (0.55) T=2.3 (0.09)

WASHER

€ 5.50

19

5135611010
ref: 19
O.D=30 (1.18) I.D=18 (0.71) T=2.3 (0.09)

WASHER

€ 2.50

20

5100011833019
ref: 20
INCLUDES REF.NO.29

STEERING STEM

€ 0.00

21

5145108010
ref: 21

FORK INNER TUBE FITTING BOLT

€ 1.50

22

5145208010
ref: 22

CLIP,SPEEDOMETER CABLE

€ 3.00

23

5145303010
ref: 23

CLIP,BRAKE CABLE

€ 5.00

24

5153011011019
ref: 24

HEAD LAMP RIGHT BRACKET

€ 0.00

24

5153011011078
ref: 24

HEAD LAMP RIGHT BRACKET

€ 0.00

24

5153011011079
ref: 24

HEAD LAMP RIGHT BRACKET

€ 0.00

25

5154011011019
ref: 25

HEAD LAMP LEFT BRACKET

€ 0.00

25

5154011011078
ref: 25

HEAD LAMP LEFT BRACKET

€ 0.00

25

5154011011079
ref: 25

HEAD LAMP LEFT BRACKET

€ 0.00

26

5155111010
ref: 26

SEAT,HEADLAMP BRACKET

€ 0.00

27

5155211010
ref: 27

PROTECTOR,OUTER TUBE,LEFT

€ 3.50

28

5155311010
ref: 28
O.D=40 (1.57) I.D=34 (1.34) T=4.8 (0.19)

CUSHION,HEADLAMP BRACKET

€ 0.00

29

5162108000
ref: 29

RACE,STEERING,OUTER,UPPER

€ 9.50

30

5163201000
ref: 30

NUT,STEERING STEM

€ 26.50

31

5621111010
ref: 31

CLAMP,HANDLEBAR

€ 8.00

32

0916626001
ref: 32
O.D=34 (1.34) I.D=26 (1.02) T=2.3 (0.09)

WASHER

€ 2.00

33

0112108251
ref: 33

SMALL HEAD HEXAGON BOLT

€ 2.50

34

0121106252
ref: 34

CROWN HEAD BOLT

€ 1.50

35

0211106101
ref: 35

CROSS HEAD SCREW

€ 1.50

36

0831211181
ref: 36

SMALL HEXAGON NUT

€ 2.00

37

0832121061
ref: 37

LOCK WASHER

€ 2.50

38

0832121081
ref: 38

LOCK WASHER

€ 2.00

39

0832121101
ref: 39

LOCK WASHER

€ 2.00
