IGNITION SWITCH-HEAD LAMP-HIGH BEAM INDICATOR LAMP-COMBINATION

ref

part #

description

quantity

1

3400010807
ref: 1
MILE & TACHOMETER

COMBINATION METER ASS'Y

€ 0.00

1

3400010806
ref: 1
KILO & TACHOMETER

COMBINATION METER ASS'Y

€ 0.00

2

3417311020
ref: 2

SPEEDOMETER LAMP SOCKET

€ 0.00

2

0004507186
ref: 2

SPEEDOMETER LAMP SOCKET

€ 0.00

3

3417411020
ref: 3

NEUTRAL LAMP SOCKET

€ 0.00

3

3417909010
ref: 3

NEUTRAL LAMP SOCKET

€ 0.00

4

3417512020
ref: 4
T20-49662

TURN SIGNAL INDICATOR LAMP SOCKET

€ 0.00

5

3418111010
ref: 5

COMBINATION METER GASKET

€ 0.00

6

3491011020
ref: 6

SPEEDOMETER CABLE ASS'Y

€ 19.50

7

3491111030
ref: 7

SPEEDOMETER INNER CABLE

€ 0.00

8

3494011020
ref: 8

TACHOMETER CABLE ASS'Y

€ 10.50

9

3494111030
ref: 9

TACHEMETER INNER CABLE

€ 0.00

10

3494311030
ref: 10

SEAL,OIL SPEEDOMETER CABLE

€ 3.00

11

3510011610
ref: 11

HEAD LAMP ASS'Y

€ 29.50

12

3511111610
ref: 12

HEAD LAMP RIM

€ 55.00

13

3512111610
ref: 13

HEAD LAMP LENS UNIT

€ 113.00

14

3512211610
ref: 14
12V 35/25W

HEAD LAMP BULB SOCKET

€ 21.00

15

3514111610
ref: 15

HOUSING

€ 0.00

16

3515111610
ref: 16

SCREW,HEADLAMP ADJUST

€ 1.00

17

3515411610
ref: 17

SPRING,HEADLAMP ADJUST

€ 1.50

18

3515911610
ref: 18

CAP,HEADLAMP BEAM HOLE

€ 2.50

19

3517711610
ref: 19

GASKET,BULB (NAS)

€ 1.00

20

3517811610
ref: 20

CLAMP,BULB

€ 3.00

21

3518111611
ref: 21

HEAD LAMP RIM FITTING SCREW

€ 0.00

22

3518911610
ref: 22

HEAD LAMP RIM FITTING SPACER

€ 0.00

23

3611811610
ref: 23

PARKING LAMP BULB SOCKET

€ 0.00

24

3633001610
ref: 24

LAMP ASSEMBLY,BEAM INDICATOR

€ 0.00

25

3633101610
ref: 25

LENS,LAMP

€ 0.00

26

3633201610
ref: 26

NUT,LENS HOLDER

€ 5.50

27

3633401610
ref: 27

HOLDER,LAMP

€ 1.00

28

3633501610
ref: 28

HIGH BEAM INDICATOR LAMP SOCKET

€ 0.00

29

3633701610
ref: 29

GASKET,LENS (NAS)

€ 3.50

30

3711011012
ref: 30

IGNITION SWITCH ASS'Y

€ 42.00

31

5181011601019
ref: 31

HEAD LAMP HOUSING

€ 83.50

31

5181011601078
ref: 31

HEAD LAMP HOUSING

€ 83.50

31

5181011601079
ref: 31

HEAD LAMP HOUSING

€ 83.50

32

5182711000
ref: 32
T20-51808

HEAD LAMP HOUSING RUBBER

€ 1.50

33

0916104002
ref: 33

HEAD LAMP RIM FITTING SCREW GASKET

€ 0.00

34

0916504001
ref: 34

WASHER (09165-04004)

€ 3.00

35

0947112001
ref: 35
12V 3W

BULB(12V3.4W,STANLEY,A72A)

€ 1.50

36

0947112004
ref: 36
12V 1.5W

BULB(12V1.7W,A71A)

€ 2.00

37

0122108252
ref: 37
T20-49661

CROWN HEAD BOLT

€ 2.00

38

0211105161
ref: 38

CROSS HEAD SCREW

€ 0.00

39

0213104121
ref: 39

CROSS HEAD SCREW

€ 1.00

40

0831111051
ref: 40

HEXAGON NUT

€ 1.00

41

0831211081
ref: 41

SMALL HEXAGON NUT

€ 2.00

42

0832121051
ref: 42

LOCK WASHER

€ 2.00

43

0832121081
ref: 43

LOCK WASHER

€ 2.00

44

0832221051
ref: 44

FLAT WASHER

€ 2.50

45

0832211082
ref: 45

SMALL FLAT WASHER

€ 2.00

all assemblies
